PROLUXE PARTS LIST FOR
DP1350
DP1350A DP1350TA DP1350B DP1350E DP1350TE DP1350CEB DP1350CEC DP1350TCEC DP1350GCEC DP1350TGCEC
120 ~ AC 120 ~ AC 240 ~ AC 208 ~ AC 208 ~ AC 240 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC
ITEM
NO.
DESCRIPTION
QTY.
53 BOLT, U.P. ADJUSTMENT 11067 11067 11067 11067 11067 11067 11067 11067 11067 11067 4
54 5/16-18 X 2-1/2" HEX BOLT GR5, DP1300 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 BH51618212G5 4
55 BOLT, HEX 1/4-20 X 5/8" ZINC PLATED BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 BH142058 4
56 HOUSING, MACHINING 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 11010252201 1
57 GREEN MUSHROOM BUTTON SCREW ON P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V P9ARB3V 2
58 SWITCH, MOM P/S OP SCREW ON GE P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO P9XPLOSO 3
59 CRANK SPACER 11064 11064 11064 11064 11064 11064 11064 11064 11064 11064 1
60 CRANK HANDLE, ADJUSTMENT 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1106001 1
61 SCREW, SET 5/16-18 X 3/8 SET SCREW KNURLED CUP POINT SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN SST5161838KN 2
62 ASSEMBLY, CONTROL FACIA 11086027 11086027 11086027 11086027 11086027 11086027 11086027 11086027 11086027 11086027 1
63 WASHER, INTERNAL TOOTH LOCK #6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 WLIT6 8
64 NUT, HEX 6-32 NH632 NH632 NH632 NH632 NH632 NH632 NH632 NH632 NH632 NH632 8
65 MARKER STRIP #7 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 MS6017 1
66 SCREW, PAN HD 8-32 X 5/8" SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 SP83258 2
67 FUSE HOLDER 1 AMP MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 MPPF708 1
68 FUSE BUSS 1 AMP MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R MPPF701R 1
69 SCREW, PHILLIPS PAN 2-56x1/4 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 SP25614 1
70 TRANSFORMER 11096975 11096975 11096975 11096975 11096975 MPPT700R MPPT700R MPPT700R MPPT700R MPPT700R 1
71 WASHER, SAE 1/4 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 WSAE14 4
72 OVERLAY-BLUE, DP1300/DP1350, DP2350/DP2300 ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B ODP2350B 1
73 DIGITAL CONTROL REV. 5.06 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 DP131052 1
74 BOTTOM COVER DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 DP13154 1
75 OPERATION MANUAL MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 MDP1350 1
76 NYLON SPACER, 1/4 X .141 X 9/32 LONG 110969111 110969111 110969111 110969111 110969111 110969111 110969111 110969111 110969111 110969111 4
77 WASHER, STEEL 311150019 311150019 311150019 311150019 311150019 311150019 311150019 311150019 311150019 311150019 4
78 SWITCH, PROXIMITY SENSOR 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 11017452377 1
79 SCREW, SET 8-32X1 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 SST8321 2
80 WASHER, INTERNAL TOOTH LOCK #8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 WLIT8 4
81 HOUSING, SWITCH PROXIMITY SENSOR 110103 110103 110103 110103 110103 110103 110103 110103 110103 110103 1
82 BOLT, HEX 7/16-20 X 1-1/2", GRADE 8 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 BH71620112 2
83 RELAY, SOLID STATE MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 MPR90217 1
84 NUT, HEX 8-32 NH832 NH832 NH832 NH832 NH832 NH832 NH832 NH832 NH832 NH832 4
85 SCREW, SOCKET FLAT HEAD 1/4-20 X 3/4 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 SF142034 1
86 SCREW, SET 3/8-16 X 1/2 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 SST381612 2
87 TERMINAL, FORK #10 10-12 GA TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 TF101012 1
88 NUT, HEX 3/4-16 MACHINED DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 DP13162 1
89 TERMINAL, #6 RING 18‐22 GA 2202 2202 2202 2202 2202 2202 2202 2202 2202 2202 3
90 CONTACT N/O SCREW TYPE, GE #P9B10VN 110101751 110101751 110101751 110101751 110101751 110101751 110101751 110101751 110101751 110101751 3
91 BUTTON BLACK MUSHROOM SCREW ON GE P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N P9ARB3N 1
92 UPPER HEAT SHROUD 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1109336 1
93 8-32 X 1/4" PHIL. HD 100 DEG., SCREW STAINLESS STEEL SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S SF83214S 4
95 WIRE, TGGT, 14 GA. (HEATER) 110069 110069 110069 110069 110069 110069 110069 110069 110069 110069 4.25 FT.
96 TFE, SHRINK TUBING 7AWG 110131 110131 110131 110131 110131 110131 110131 110131 110131 110131 .33 FT.
97 TERMINAL, RING #6 14-16 GA HIGH TEMP 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1601HT 1
98 TERMINAL, RING #8 14-16 GA 1604 1604 1604 1604 1604 1604 1604 1604 1604 1604 2
99 TERMINAL, QD 3/16 X 18-22 GA 2280 2280 2280 2280 2280 2280 2280 2280 2280 2280 2
100 WASHER, SAE #6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 WSAE6 1
101 SCREW, PAN HEAD 6-32 X 1/4 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 SP63214 1
102 WIRE, TFE 14GA. GREEN WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G WTFE14G 1.5 FT.
103 RTD, SENSOR ASSEMBLY 110949110 110949110 110949110 110949110 110949110 110949110 110949110 110949110 110949110 110949110 1
104 SLEEVING, PVC WIRE OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 OPVC1050 .16 FT.
