PROLUXE PARTS LIST FOR
DP1350
DP1350A DP1350TA DP1350B DP1350E DP1350TE DP1350CEB DP1350CEC DP1350TCEC DP1350GCEC DP1350TGCEC
120 ~ AC 120 ~ AC 240 ~ AC 208 ~ AC 208 ~ AC 240 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC 220 ~ AC
ITEM
NO.
DESCRIPTION
QTY.
105 SCREW, SET 1/4-20 X 1/2" SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 SST142012 1
106 SCREW BUTTON HEAD 3/8-16 X 1/2 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 SB381612 4
107 HYDRAULIC MOTOR HOSES DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 DP13141 2
108 HYDRAULIC PUMP/MOTOR WITH OIL CANISTER (DP1350,DP2350) DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 DP13149 1
109 90 DEGREE ELBOW X-LONG FORGE DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 DP13158 2
110 POWER CORD 110969174 110969174 110969175 110969175 110969175 MPPW202 MPPW202 MPPW202 DP149203 DP149203 1
111 STRAIN RELIEF 3231 3231 3231 3231 3231 3231 3231 3231 3231 3231 1
112 WIRE HARNESS DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 DP13150 1
113 CABLE, POWER DISTRIBUTION DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 DP13168 1
114 PORT FITTING DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 DP13121 2
115 PAN HEAD SLOTTED 8-32 X 3/8" PLATED SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 SPS83238 4
116 TUBING, BLACK AIR LINE 1/4" TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 TPE4014 1 FT.
117 BOLT, HEX 5/16-18 X 1 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 BH516181 2
118 WASHER, LOCK 7/16 WL716 WL716 WL716 WL716 WL716 WL716 WL716 WL716 WL716 WL716 2
119 RAIL LOCK DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 DP13122 2
120 FITTING, AIR 1/4" FEM.PIPE X, 1/4 TUBE 90 DEGREE AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 AQ70P4X4 1
121 MUFFLER SILENCER QUIET FLOW 1/4" NPT SQF-2 110559029 110559029 110559029 110559029 110559029 110559029 110559029 110559029 110559029 110559029 1
122 NUT, CONDUIT 1/2" NC12 NC12 NC12 NC12 NC12 NC12 NC12 NC12 NC12 NC12 1
123 SCREW, SET 1/4-20 X 1/4 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 SST142014 1
124 BRIDGE, PLUG IN, 2, RED, CROSS CONNECTIONS 110116920 110116920 110116920 110116920 110116920 110116920 110116920 110116920 110116920 110116920 2
125 WASHER, SAE 7/16 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 WSAE716 4
126 BOLT HEX 3/8-16X1 STAINLESS STEEL BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S BH38161S 1
127 SCREW, SET 10‐32 X 3/16" SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 SST1032316 2
128 TERMINAL RING 12-10 GA #6 1402 1402 1402 1402 1402 1402 1402 1402 1402 1402 4
129 TERMINAL BLOCK #11 60111 60111 60111 60111 60111 60111 60111 60111 60111 60111 1
130 MARKER STRIP #11 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 MS60111 1
131 PIVOT ARM CLOSURE PLUG DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 DP13161 1
132 FITTING, AIR 1/4" PIPE X 1/4" TUBE, 90 DEGREE AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 AQ69P4X4 1
A1 KITTED, UPPER PLATEN COMPLETE ASSEMBLY 11010253110 110079120AK 110102531101 110079208PAK 110079208AK 110102531101 110079220PAK 110079220AK 110079220PAK 110079220AK 1
A2 KITTED, UPPER PLATEN WITH WIRING ONLY 110102531200 110079120K 110102531201 110079208PK 110079208K 110102531201 110079220PK 110079220K 110079220PK 110079220K 1
A3 KITTED, LOWER PLATEN ASSEMBLY 11032A 11032TA 11032A 11032A 11032TA 11032A 11032A 11032TA 11032A 11032TA 1
A4 SWITCH, PROXIMITY SENSOR, KIT 110103K 110103K 110103K 110103K 110103K 110103K 110103K 110103K 110103K 110103K 1
A5 CRANK, ASSEMBLY 11061A 11061A 11061A 11061A 11061A 11061A 11061A 11061A 11061A 11061A 1
A6 START SWITCH ASSY MUSHROOM 11051845 11051845 11051845 11051845 11051845 11051845 11051845 11051845 11051845 11051845 2
A7 STOP SWITCH ASSY MUSHROOM 11051850 11051850 11051850 11051850 11051850 11051850 11051850 11051850 11051850 11051850 1
DP1350 RH 051820 CUSTOMER MANUAL
