Ethernet Reader Quick Start
Connect Reader to Ethernet Network
Step 1
Connect the ER750/ER755
reader to an Ethernet hub via
the Ethernet cable.
Note:
Or you can connect the
ER750/ER755 reader to your
PC/Laptop directly by one
Ethernet cable.
Step 2
Connect the power (DC12V) to
the pin VCC and GND.
Note:
Or you can connect an
ER750-10/ER755-10 reader to
your P.O.E HUB
Connect Reader to Ethernet Network
+
-
DC12V
