Ensure the machine is stable on rm level ground before use.
Bolt the machine to a solid base or the Oponal Trolley Base.
ALWAYS disarm the machine before any loading, adjustment or maintenance.
ALWAYS load clays from rear and ONLY if the machine is disarmed and safe.
NEVER approach the machine from the front or sides. ALWAYS from the rear.
NEVER allow children or untrained persons to approach or touch the machine.
NEVER move an armed/loaded machine. ALWAYS disarm and disconnect baery.
REMOVE the main throwing spring before Transport in a vehicle.
BE AWARE of the fall zone of both broken and unbroken clays and that a change in
wind direcon will aect this.
Posioning the machine
1. Clay Target Launchers must be situated on rm level ground in a posion that
will allow unrestricted access to rear of machine.
2. There must be no obstrucons to the path of the throwing arm.
3. Ensure that the power supply can be easily disconnected and cables cannot
become tangled in any part of the mechanism.
Firing the machine
1. Turn the ON/OFF or switch (if ed) to the ON or posion and set
the ARM/DISARM switch to the ARM/LOAD posion. The machine will
move automacally and arm itself ready to launch a loaded clay.
2. Press the FIRE buon on the command cable to throw a clay.
3. The machine will re every me the FIRE buon is pressed and will auto-
macally rearm itself, unl disarmed and switched o or disconnected.
Disarming the machine
1. To disarm the machine push the ARM/DISARM switch upwards to the DIS-
ARM posion and immediately release (long enough for the trap to re, but
not giving the machine a chance to rearm).
2. Turn the ON/OFF or switch (if ed) to the ON or posion and dis-
connect the baery.
