Safe Mode Procedure - Warning: Stand at rear of machine only
1. Disarm the machine by icking the ARM/DISARM switch upwards towards the
DISARM posion and immediately releasing (long enough for the trap to re, but
not giving the machine a chance to rearm). The Gearbox block (A rectangular
block aached to the gearbox sha) should stop in a posion poinng towards
the front of the machine.
2. If the Gearbox block is poinng directly towards the front of the machine, push
the ARM/DISARM switch momentarily in direcon of DISARM/NUDGE just
enough to allow the block past its forward poinng posion.
3. If the block has gone too far, rearm the machine and then disarm again unl
the desired posion is achieved.
4. Disconnect the baery/power source from the machine once the block is in
the correct posion.
5. With the Gearbox block now poinng just past the forward poinng posion,
the throwing arm can be pushed slowly, USING THE PALM OF THE HAND ONLY,
around counter clockwise .
6. As the throwing arm gets to the ring posion (poinng direct to the back of
the machine) the spring will take over, at which point the drive bolt on the Gear-
box block stops the arm, and prevents it from ring.
This is SAFE MODE the arm is now trapped between the drive bolt in one direc-
on and locked on the one-way bearing within the trap, it cannot move or re-
lease again unl power is applied and the ARM/DISARM switch operated.
