Promax RG6-E-230V - A) Operating Your RG6-E

Advanced Test Products RG6-E
OPERATING YOUR RG6-E
CONTROLS
NOTE: To change from Recovery mode to Purge:
Close the Inlet port, turn the unit off (to prevent high pressure shutoff), switch
to Purge position and turn the Inlet port to the Purge position, restart the unit.
NORMAL RECOVERY
SELF PURGE / AUTO EVACUATE
4
