Speaker Systems
ProMaxX
6
600W RMS + 300W RMS
133dB SPL
Processed Active Speaker
> 2-way, bi-amplified, bass
reflex design cabinet
> 320 mm (12”) LF
neodymium magnet woofer
with 75 mm (3”) voice coil,
custom made for FBT by
B&C
> 25mm (1”) exit throat B&C
HF neodymium magnet
compression driver
> Frequency response from
48Hz to 20 kHz
> Biamped: 600W RMS
LF, 300W RMS HF, Class
D power amplifiers with
switch mode power
supplies
> Digital signal processor with
8 equalization presets
600W RMS + 300W RMS
135,5dB SPL
Processed Active Speaker
> 2-way, bi-amplified, bass
reflex design cabinet
> NEW! 355 mm (14”) LF
neodymium magnet woofer
with 75mm (3”) voice coil,
custom made for FBT by
B&C
> 35 mm (1,4’’) exit throat
B&C HF neodymium
magnet compression driver
with 64 mm (2,5”) voice coil
> Frequency response from
45Hz to 20 kHz
> Biamped: 600W RMS
LF, 300W RMS HF, Class
D power amplifiers with
switch mode power
supplies
> Digital signal processor with
8 equalization presets
> Control Panel: features XLR
> Control Panel: features XLR
input and link out, Volume,
EQ Presets, HP Filter,
Ground-Lift Switch
> 90°H x 60°V constant
directivity horn
> Sturdy gas-injected
polypropylene molded
enclosure with 2 integrated
handles
> 2 x M10 suspension points,
35mm (1,3/8”) top-hat
speaker stand socket, wall
bracket mount flange plate
> Dual Purpose: Front of
House or Stage Floor
Monitor: with 12°, 40° and
55° monitoring angles
> Extremely light, only 15 kg
(33,1 lb)
input and link out, Volume,
EQ Presets, HP Filter,
Ground-Lift Switch
> 90°H x 60°V constant
directivity horn
> Compact Dimensions:
ProMaxX 14a uses the
same size gas-injected
polypropylene molded
enclosure as the ProMaxX
12a, but features our New
14” LF Woofer for more
low frequency SPL
> Dual Purpose: Front of
House or Stage Floor
Monitor: with 12°, 40° and
55° monitoring angles
> 2 x M10 suspension points,
35 mm (1,3/8”) top-hat
speaker stand socket,
wall bracket mount
flange plate
> Extremely light, only
16,5 kg (36,4 lb)
600 W / 8 ohms
130dB SPL
Passive Sound
Reinforcement Speaker
> Passive version,
recommended amplifier
600W RMS @ 8 ohms
> Built-in passive crossover
with soft-trip protection for
the LF woofer and HF driver
> Speakon NL-4 IN and LINK
OUT connectors
700W / 8ohm
132dB SPL
Passive Sound
Reinforcement Speaker
> Passive version,
recommended amplifier
700W RMS @ 8 ohms
> Built-in passive crossover
with soft-trip protection for
the LF woofer and HF driver
> Speakon NL-4 IN and LINK
OUT connectors
ProMaxX 14a
ProMaxX 14
ProMaxX 12a ProMaxX 12
