Speaker Systems
ProMaxX
7
600W RMS + 300W RMS
131dB SPL
Processed Active Speaker
> 2-way, bi-amplified, bass
reflex design cabinet
> 250 mm (10”) LF
neodymium magnet
woofer with 64mm (2,5”)
voice coil, custom made
for FBT by B&C
> 25mm (1”) throat exit B&C
HF neodymium magnet
compression driver
> Frequency response from
58Hz to 20 kHz
> Biamped: 600W RMS
LF, 300W RMS HF, Class
D power amplifiers with
switch mode power
supplies
> Digital signal processor with
8 equalization presets
1200W RMS
136dB SPL
Processed Active Subwoofer
> Compact band-pass design
subwoofer with high SPL
and punch
> 380 mm (15”) high excursion
woofer with 75 mm (3”)
voice coil, custom made for
> Control Panel: features XLR
input and link out, Volume,
EQ Presets, HP Filter,
Ground-Lift Switch
> 90°H x 60°V constant
directivity horn
> Sturdy gas-injected
polypropylene molded
enclosure with one
integrated handle
> 2 x M10 suspension points,
35 mm (1,3/8”) top-hat
speaker stand socket, wall
bracket mount flange plate
> Dual Purpose: Front of
House or Stage Floor
Monitor: 12°, 40° and 55°
monitoring angles
> Extremely light, only 11,2 kg
(24,7 lb)
FBT by B&C
> Frequency response from
38Hz to 120Hz
> 1200W RMS Class D power
amplifier with switch mode
power supply
> Digital Signal Processor
with 8 presets, 2
equalization with 4 LPF
different frequency
> Control Panel with XLR input
and link out, Volume, EQ
Presets, Delay, Phase Switch
0°-180°, Ground-Lift Switch
> 15mm (5/8”) Baltic birch
plywood cabinet with
scratch & scuff resistant
paint finish
> M20 (20 mm) top mount
speaker stand socket, two
aluminum carrying handles
> Provides additional low
frequency reinforcement
when used along with 2 -
way ProMaxX speakers
400W / 8 ohms
127dB SPL
Passive Sound
Reinforcement Speaker
> Passive version,
recommended amplifier
400W RMS @ 8 ohms
> Built-in passive crossover
with soft-trip protection for
the LF woofer and HF driver
> Speakon NL-4 IN and LINK
OUT connectors
ProMaxX 10a
ProMaxX 15Sa
ProMaxX10
ProMaxX 15Sa control panel
