36 ActivPanel Titanium System Install and User Guide
3
4
70” 75" 86"
A 1668mm (65.7") 1764mm (69.5") 2014mm (79.3")
B 1033mm (40.7") 1089mm (42.9") 1231mm (48.5")
C 153-344mm (6.0-13.5") 211-402mm (8.3-15.8") 282-473mm (11.1-18.6")
D 600mm (23.6") 800mm (31.5") 800mm (31.5")
E 137mm (5.4") 134mm (5.3") 135mm (5.3")
