Step 4: Setting Up Data Cable Connections
15
Figure 17.VTrak J610s and J310s I/O modules have one subtractive-routed
port and one table-routed port
Each I/O module has one subtractive-routed external receptacle (CN1) and one
table-routed external receptacle (CN2).
Note
SAS HBA cards are User-supplied items. They are not included
with the VTrak unit.
115200
8 N 1
Subtractive Connector (CN1) LED
Table Connector (CN2) LED
I/O Module Status LED
