VTrak J610s, J310s Quick Start Guide
4
Figure 4. VTrak J310s rear view
Some J610s and J310s units ship with a single I/O module and a dummy module
installed in the place of the second I/O module.
O
I
O
I
115200
8 N 1
115200
8 N 1
Cooling Unit 1
Power Supply 1
Power Supply 2
I/O module 2
Cooling Unit 2
I/O module 1
