1. Lay down the lateral support #3 and horizontal support #2 and hook the corner bracket #5 before screwing down the supports with #9.
2. Repeat the same process for each corner (Unscrew and adjust as needed)
3. Align the end frame with the mounting holes on the corner brackets and fully tighten using the provided tool #11.
ASSEMBLY INSTRUCTIONS
LOCK DESK
A
DETAIL
A
SCALE
1 : 1
PRO@PROPROFFICE.COM 718 855 6519 PROPROFFICE.COM 3
