ProScan PLDED3281 - WALL MOUNT INSTALLATION; INSTALLING; REMOVING THE BASE STAND; MOUNTING ON THE WALL

1*--
The length of the two screws(size M6 screw) should not exceed 12 mm.
2*--When installing a wall hanging, please remove the shell after the two ST6 x 10
self-tapping screws (see chart), put on the hanging bracket, use remove ST6 x 10
self-tapping screw assembly in the original position (not screws substitute) with it.
11
Screws
4 pcs
Front
(long)
Front
(long)
Front
(long) (Short)
Screw holes
1
2 3
1*
2*
200mm
200mm
7.9’’ x 7.9’’
(200mm x 200mm)
