Base installation guide
Material commodity
Damping ring
stator
screw(six)
Plastic base
Please refer to picture operation method,
the damping ring in the column.
Will base in the column.
Please refer to picture operation method,
Base distinguish between front and rear.
Note:
front
behind
(Behind the audience)
Please refer to picture operation method,
lobe
Concave part
The stator into alignment positioning fixed hole location.
Please refer to picture operation method,
Screw fixed base location piece.
NOTE: This product is very heavy, assembly of 2 people above
To Next Page
