Page #2 background imageLoading...
Page #2 background image
Changing modes:
The QPS will be in the “Run Mode” when it is powered on, displaying PV and SV. Press ;
for more than 2 seconds in this mode to switch to the “Quick Setup Mode”. Press ; for
more than 4 seconds in the “Run Mode” to switch to “Pro Setup Mode”. Press ; more than
2 seconds in the “Quick Setup Mode” or “Pro Setup Mode” to return to the “Run Mode”.
Setting up parameters:
In the three modes, press ; once to select the parameter to set up. When you find the
parameter to set up or modify, use , . to modify the setting.
Menu Navigation
Resetting the ProSense QPS to factory default values:
Hold ; button for 4-5 seconds until display changes to read Pro. Press the ; button 9
times until the display shows
off
rst
Using the ,. buttons change the value to on and press ;
When complete the display will read
std
sub
Caution: Outputs remain active in Setup Mode
Pro Setup Mode
Quick Setup
Mode
QPS Powered ON
Run Mode
Press ; > 4 secs.
Press ; > 2 secs.
Press
;
> 2 secs.
Press ; > 2 secs.
Accessing QPS Setup Modes:
;
;
;
;
;
Run Mode
Upper limit of OUT1
Lower limit of OUT1
Upper limit of OUT2
Lower limit of OUT2
SV
SV
–1-h
–2-h
–2-l
–1-l
–1-p
–2-p
OUT1 set to
Hysteresis or Window
Mode
OUT2 set to
Hysteresis or Window
Mode
OUT2 set to
Easy Mode
OUT1 set to
Easy Mode
Run Mode
Run Mode
1-H
Output 1 high setpoint for hysteresis or window modes
1-L
Output 1 low setpoint for hysteresis or window modes
1-P
Output 1 high setpoint for easy mode
2-H
Output 2 high setpoint for hysteresis or window modes
2-L
Output 2 low setpoint for hysteresis or window modes
2-P
Output 2 high setpoint for easy mode
;
;
;
;
;
Quick Setup
Mode
OUT1 mode
OUT2 mode
NO/NC of OUT1, OUT2
Output response time
Unit
PV display color
;
;
easy
–ot1
.
,
.
,
–hys
–ot1
WCMp
–ot1
easy
–ot2
.
,
.
,
–hys
–ot2
WCmp
–ot2
1o2o
–noC
.
,
.
,
1C2o
–noC
1o2C
–noC
.
,
1C2C
–noC
Easy
Hysteresis
Window
Easy
Hysteresis
Window
–––2
–spd
.
,
.
,
–––4
–spd
––10
–spd
.
,
––50
–spd
OUT1 N.O.
OUT2 N.O.
OUT1 N.C.
OUT2 N.O.
OUT1 N.O.
OUT2 N.C.
OUT1 N.C.
OUT2 N.C.
.
,
––30
–spd
.
,
–100
–spd
.
,
–250
–spd
.
,
–500
–spd
.
,
1000
–spd
.
,
5000
–spd
Unit: ms
r-on
–Clr
.
,
.
,
6-on
–Clr
–red
–Clr
.
,
6ren
–CLr
–Mpa
–unt
.
,
.
,
–Kpa
–Unt
–K6f
–unt
.
,
–psi
–unt
.
,
–bar
–unt
.
,
mmh6
–unt
.
,
cmh6
–unt
.
,
inh6
–unt
MPa* kPa** kgf/cm² bar psi
mmHg** cmHg*
inchHg
* Will not be displayed in low pressure type sensor. (QPSL)
** Will not be displayed in high pressure type sensor. (QPSH)
Quick Setup Mode
Additional Help and Support
For additional technical support and questions, call our Technical
Support team @ 1-800-633-0405 or 770-844-4200
;
;
;
;
Pro Setup
Mode
SV/Setup Item Display
;
;
–std
–sub
.
,
.
,
–off
–sub
unit
–sub
–100
–dsp
.
,
.
,
–250
–dsp
–500
–dsp
Display SV
Off
Display unit
–––1
–hys
.
,
.
,
–––2
–hys
–––3
–hys
.
,
–––5
–hys
.
,
–––4
–hys
.
,
–––6
–hys
.
,
–––7
–hys
.
,
–––8
–hys
–off
–pWs
.
,
––on
–pws
out1
–dpy
.
,
.
,
out2
–dpy
–and
–dpy
.
,
––or
–dpy
0000
–Cod
.
,
0000
–002
–Pro
–set
Display Response Time
Switching Color Display
1000
–dsp
.
,
.
,
Cp-m
–Cpy
Power Saving
Hysteresis
Code
–off
–Cpy
.
,
Cp-5
–Cpy
Copy Mode
–off
–Asw
.
,
––on
–asw
Analog Output Enable
–off
–rst
.
,
––on
–rst
Reset to Default Settings
;
;
;
;
Slave mode
Master mode
Pro Setup Mode
Copyright 2017, Automationdirect.com Incorporated/All Rights Reserved Worldwide
Data Sheet: QPS-QSG
P.2
See “Code” for details
Quick Setup Mode
ot1
Mode Selection for Output 1
ot2
Mode Selection for Output 2
EASY
Easy Mode (Default) (see examples on Page 4)
HYS
Hysteresis Mode (see examples on Page 4)
WCmP
Window Mode (see examples on Page 4)
noC
Normally Open /Normally Closed output selection
1o2o
Output 1 Normally Open & Output 2 Normally Open (Default)
1C2o
Output 1 Normally Closed & Output 2 Normally Open
1o2C
Output 1 Normally Open & Output 2 Normally Closed
1C2C
Output 1 Normally Closed & Output 2 Normally Closed
Spd
Output Response Time in milli-seconds - use to minimize digital output fluctuations due to pressure variations
(Default = 2)
CLr
Color - set how display color will change based on parameter dPY in Pro Setup Mode
r-on
PV display turns red based on output status as set by parameter dPY in Pro Setup Mode (Default)
6-on
PV display turns green based on output status as set by parameter dPY in Pro Setup Mode
rEd
PV display is always red regardless of Out1 and/or Out2 state
6rEn
PV display is always green regardless of Out1 and/or Out2 state
Unt
Select Engineering Units
Engineering Units Display Resolution
QPSH QPSL
MPa
MPa available only on QPSH-Ax-42 0.001 -
Kpa
kPa- available only on QPSL-Ax-42 - 0.1
k6f
kgf/cm² 0.01 0.001
bAr
bar 0.01 0.001
PSi
psi (Default) 0.1 0.01
MMH6
mm Hg available only on QPSL-Ax-42 - 1
CMH6
cm Hg avalialbe only on QPSH-Ax-42 1 -
InH6
inch Hg 1
0.1
Pro Setup Mode
Pro
Pro Setup Mode - Displays when entering Pro Setup Mode
Set
Setup - Displays when entering Pro Setup Mode
sub
SV / Setup Item Display selection
std
Display shows SV (Default)
off
OFF
unit
Display shows Engineering unit, set by Unt in Quick Setup Mode
dsp
Display response time rate in milli-seconds (Default = 100)
Hys
Hysteresis setting for outputs in EASY and WINDOW modes (Default = 3), applies to both outputs
QPSH
MPa(MPa)
1 = 0.001 MPa thru 8 = 0.008 MPa -
kPa(KpA)
- 1 = 0.1 kPa thru 8 = 0.8 kPa
kgf/cm²(k6f)
1 = 0.01 kgf/cm² thru 8 = 0.08 kgf/cm² 1 = 0.001 kgf/cm² thru 8 = 0.008 kgf/cm²
bar(bAr)
1 = 0.01 bar thru 8 = 0.08 bar 1 = 0.001 bar thru 8 = 0.008 bar
psi(PSI)
1 = 0.1 psi thru 8 = 0.8 psi 1 = 0.01 psi thru 8 = 0.08 psi
mm Hg(MMH6)
- 1 = 1 mm Hg thru 8 = 8 mm Hg
cm Hg(CMH6)
1 = 1 cm Hg thru 8 = 8 cm Hg -
In Hg(InH6)
1 = 1 in Hg thru 8 = 8 in Hg 1 = 0.1 in Hg thru 8 = 0.8 in Hg
pWs
Power Saving Mode - Turns display back light off. Display values can be viewed momentarily by
pressing the ; button
dpy
Switching color display - sets when display changes colors (as set by parameter CLr) based on output
status
out1
Color changes when Output 1 is ON (Default)
out2
Color changes when Output 2 is ON
and
Color changes when Output 1 and Output 2 are ON
or
Color changes when Output 1 or Output 2 is ON
Cod
Code - quick reference to determine the settings of the QPS device (See Code Reference Table - Page 3)
CPY
Copy - used to select master and slave when copying settings to other QPS devices
CP-s
Copy Slave Mode
CP-m
Copy Master Mode
Asw
Analog Output Enable (Default = ON)
rst
Reset QPS to Factory Defaults
