F
E
D
G
RIGHT
LEFT
Insert the crank into the tilt socket. Turn the crank clockwise or
counter-clockwise to tilt the canopy.
Please note that the umbrella catches more wind when tilted and
so the tilt feature should be used with extreme caution
OPERATING THE UMBRELLA
6
9
ASSEMBLING THE UMBRELLA
Secure the umbrella with screws using the included allen wrench (F).
Fix the crank by allen wrench (G).
