Hunting test
Plug in the target cable (RJ45, RJ11, USB, BNC, 1394) that
wanted to find, press “ON/OFF” button, power on with a long
sound then press “SCAN” button, LCD will show as following
figure.
Select frequency (the number showed on bottom of LCD)
depends on tested circuit (there are 9 kinds of selectable
frequencies, press “SCAN” button to change it. (Number 1 to
9 then back to 1.).
Open the battery compartment cover of receiver then install
9V battery. Press “TEST” button, the “POWER” LED will light
up, then take the receiver and make the probe part
approaching the numerous cables and find target wire. When
receiver closes to the target cable, sound will be louder.
Extra functions
(1) Low battery indication
When the battery is low, LCD will show flash “
” icon.
Please replace battery.
(2) LCD backlight function
Press the LIGHT key on transmitter panel, LCD
backlight will light up, and around 10 seconds lights off
automatically.
19
