Prostat PAR-809C - Testing PWA-805 Wrist Strap Auditor Performance

4. Plug the two meter test lead banana plugs into the PAR-809C receptacles.
5. Rotate the PAR-809C’s Posion Selector knob to Posion 1, the lowest resistance reference.
6. Turn ON the PAR-809C’s posion indicang lights by sliding the  switch located on the
side of the instrument to the ON posion.
7. Turn the Meter switch to the connuity posion, push the test buon on the meter and record
the measurement.
8. Vary the PAR-809C reference resistance by rotang the  on the face of
the PAR-809C to the next posion; record measurement as in step 7.
9. Select the 10 V posion on the Megohmmeters, push the  on the Megohmmeter
and record measurement.
10. Vary the PAR-809C reference resistance by rotang the posion Selector Knob on the face of
the PAR-809C to successive posions, and record measurements as in step 9.
11. The indicated resistance of the Megohmmeter should be within 10 percent of the factory resis-
tance indicated on the PAR-809C Calibraon sheet for each posion tested.
D. Conrming Funconal Performance of the PWA-805 Wrist Strap Auditor

The PRS-812 or PRS-801 is used for this funconal test procedure.
1. Check the  funcon of the Resistance Meter; replace baeries if indicaon is .
2. Turn the Resistance Meter to its  posion
3. Install the meter test leads into the proper receptacles.
4. Plug the tow test lead banana plugs into the PWA-805 Meter receptacles
5. Plug the two supplies test leads into the PAR-809C receptacles
6. Aach an alligator clip (not provided) to one PAR-809C test lead. Aach the alligator clip to the
Right hand cu cylinder of the PWA-805 Wrist Strap Auditor.
7. Install the second PAR-809C test lead banana plug in the PWA-805 Cord receptacle
8. Posion the PWA-805 three way rocker switch to its middle posion, marked “”.
9. Rotate the PAR-809C’s posion Selector knob to Posion 1, the lowest resistance reference
10. Turn ON the PAR-809C posion indicang lights by sliding the  switch located on the
side of the instrument to the ON posion.
11. Turn the resistance meter on in the AUTO mode. Push the Test buon on the meter and record
the measurement.
8
Rev. B / January 2012
PAR-809C Variable Resistance Reference
