8. Technical Specifications
SAR
IDT 77252
Theoretical Network Data Transfer Rate (OC3) : 155.52 Mbps Full Duplex
Practical Data Transfer Rate : 135 Mbps
Simultaneous connections:
16384
VPI/VCI:
14-bit encoding
ATM and SONET Standard Compliance:
SONET/SDH, STS/STM-1/OC3
AAL5, AAL0,
CBR, VBR, UBR, ABR (SAR)
UNI 3.0, UNI 3.1 (ILMI included)
LAN Emulation (LANE) v1.0
Classical IP (CIP - RFC 1577)
PROATM-V155F Multimode Fiber Port:
multimode fiber, max 2 km.
Connector: Duplex SC
Wavelength: 1310 nm
Sensitivity: -29 dBm
Output Power: -20 to -14 dBm
Maximum power on input: -14 dBm
PROATM-V155FM Single mode Fiber Port:
single mode fiber, max 15 km.
Connector: Duplex SC
Wavelength: 1310 nm
Sensitivity: -38 dBm
Output Power: -15 to -8 dBm
Maximum Input Power : -6dBm
Class I laser product compiles with IEC 60825-1
Complies with Telcordia GR-468-CORE
PROATM-V155FLH Single mode Long Reach
Fiber Port:
single mode fiber, max 40 km.
Connector: Duplex SC
Wavelength: 1310 nm
Sensitivity: -38 dBm
Output Power: -8 to -5 dBm
Maximum Input Power : -6dBm (does not support a loop-back
without an attenuator)
Class I laser product compiles with IEC 60825-1
Complies with Telcordia GR-468-CORE
On board memory: 2 MB
Indicators:
Red: Network Link
Green: Driver is running
PCI Bus: 3.3V/5V, 32-bit, version 2.2
Operating Voltage and Current: 5V, 1 A max
Operating Temperature:
5° C to 50° C (41° to 131° F)
Operating Humidity:
10% to 90%, non condensing
MTBF: 700 000H
Size: 125 mm x 82 mm
Compliance: FCC Part-15 class B
CE Marking :
Safety: EN50082-1
Emissions: EN 55022 Class A
RoHS: 5/6
