Loop Commissioning Manual
001
Address Serial No
LOOP 1 of 4
Add
INPUT DEVICE
OUTPUT DEVICE
Leave
blank
Not
Used
001
002
INPUT DEVICE
OUTPUT DEVICE
Leave
blank
Not
Used
002

A Guide on how to attach Bar-codes to the
Algo-Tec™ 6400 Loop Commissioning Manual....
...please refer to the following diagrams:-
Rear of a
6000 sensor
1E8ABB
1E8ABB
1E8ABB
6000/OPHT
OPTICAL/HEAT FIRE SENSOR
pt EN54 pt7 1997
(WHEN RUNNING MXI SYSTEM PROTOCOL)
Nelson, UK
BB9 6RT
Device Bar-code Label
Combined Sounder.
The 'combined sounder' can share
the same address number as the sensor
or have its own individual address number.
Remove ONE of the ‘Device Bar-code’ label
GREEN Line and place next to the
appropriate address OUTPUT address box
with the GREY Line on the following sheets.
Sensor
Sensors 6000/ION, 6000/OPT,
6000/OP, 6000/TEMP.
Remove ONE of the ‘Device Bar-code’
label (WHITE) and place next to the
appropriate address INPUT number
on the following sheets.
a: Sensor ONLY
b: Sensor complete with
b: Combined Sounder
Loop Commissioning Manual
001
Address Serial No
LOOP 1 of 4
Add
INPUT DEVICE
OUTPUT DEVICE
Leave
blank
Not
Used
001
002
INPUT DEVICE
OUTPUT DEVICE
Leave
blank
Not
Used
002

6000 sensor
Sounder Base
Device Bar-code Labels on
the side of the sounder.
Loop Sounder Base
ASB2, ASB4, ASBEA2 & ASBEA4.
1E8ABB
1E8ABB
1E8ABB
6000/OPHT
OPTICAL/HEAT FIRE SENSOR
pt EN54 pt7 1997
(WHEN RUNNING MXI SYSTEM PROTOCOL)
Nelson, UK
BB9 6RT
6000
sensor
