11
Ensure the Rock Spike diverter lever (if fitted) is in the pulled towards position
otherwise operating the slew control lever will operate the rock spike extractor
function.
As the control is mounted to the slew arm, it will move with operation of the slew
control. The operator must work in the control area of the post driver to avoid
all trapping zones.
Telescopic Slew Arm Control
Operating the Telescopic control lever extends and retracts the inner slew arm
through 800mm.
As the control is mounted to the inner slew arm, it will move with operation of
the telescopic control. The operator must work in the control area of the post
driver to avoid all trapping zones.
Telescopic
