protech Enigma XTR Scale 1/8 4WD - Servo Saver Assembly

14
Assembly of the servo saver / Montage van de servo saver
Assemblage du sauve-servo / Montierung des Servo Saver
3mm x 12mm (x2)
MA2183 (10pcs)
3mm x 16mm (x2)
MA2069 (10pcs)
3mm x 16mm (x2)
MA2033 (10pcs)
3mm x 8mm (x2)
MA2031 (10pcs)
3mm x 5mm x 0,5mm
Brass shim (x2)
SERVO SAVER SET
SAUVE-SERVO COMPLET
SERVO-SAVER SET
SERVO-SAVER SATZ
T56.053
3mm x 16mm
3mm x 8mm
3mm x 8mm
Brass washer 3mm x 5mm (x2)
Servo-saver connector
Barre de liaison de sauve-servo
Servo saver verbinder
Servo Saver verbindung
T56.097
3mm x 16mm
Servo saver shaft
Axe sauve-servo
Servo saver as
Servo-saver welle
T56.098
3 x 6 mm (x4)
Bushing
Entretoise
Afstelring
Distanzbughsen
For spare part, use
the optional ball
bearing T56.102
Bushing (x2)
Entretoise (x2)
Afstandsbus
Distanzbuchse
T56.099
Shaft + Spring
Axe + ressort
As + veer
Achse + Feder
T56.101
Servo saver arms
Bras sauve-servo
Servo saver
Servo-saver
T56.100
3mm x 16mm
3mm x 12mm (x2)
Approx. 20mm
Turnbuckle
Barre de réglage
Stang
Gestange
T56.072
Plastic steering link 7mm
Chape plastique
Kogelgewrichten
Kugelgelenk
T55.011
Ball link
Rotule
Kogel
Kugel
T55.028
3mm x 16mm
Approx. 19mm
3mm x 12mm (x3)
Triangle spacer
T0600.065
8 x 5 x 3 mm (x4)
Bushing
Entretoise
Afstelring
Distanzbughsen
For spare part, use
the optional ball
bearing T0684.202
