protech Nitro 12 User Manual

Tech Nitro - 26
14 16
15
T0660.045 REAR BULKHEAD 2pcs T0660.046 BACK BULKHEAD 1pcs T0660.212 2 SPEED SHAFT 1pcs T0660.048 BRAKE CAM SET T0660.049 BRAKE LEVER 1pcs T0660.050 BRAKE PADS 2pcs T0660.051 BRAKE DISK 1pcs
T0660.044 18T BELT PULLY SET
T0660.054 BRAKE ADAPTER 1pcs
T0660.053 REAR DRIVE BELT 1pcs
T0660.222 MAIN GEAR 42T ` T0660.223 MAIN GEAR 43T T0660.224 MAIN GEAR 46T T0660.225 MAIN GEAR 47T
T0600.062 5x10x4mm BALL BEAR- INGS T0660.202 10x15x4mm BALL BEAR- INGS
T0660.052 10mm PLASTIC BUSHING T0660.038 2x10 PIN
T0660.038 2x10 PIN
T0660.212 2 SPEED SHAFT 1pcs
T0660.054 BRAKE ADAPTER
T0660.044 18T BELT PULLY SET
4mm E-CLIP
T0660.045 REAR BULKHEAD (LEFT)
4mm E-CLIP
4mm E-CLIP
T0660.051 BRAKE DISK
T0660.050 BRAKE PADS 2pcs
M3x10mm screws
M3x10mm T/P SCREWS
T0660.046 BACK BULKHEAD
T0660.048 BRAKE CAM SET
T0660.202 10x15x4mm BALL BEAR INGS
T0600.062 5x10x4mm BALL BEARINGS
LONG SIDE
T0660.222 MAIN GEAR 42T ` T0660.223 MAIN GEAR 43T
T0660.224 MAIN GEAR 46T T0660.225 MAIN GEAR 47T
2x10mm PIN
T0660.044 18T BELT PULLY SET
M3x3mm SET SCREW
M3x3mm SET SCREW
5x11mm WASHER
LEAVE A GAP OF 5MM FOR THE BRAKE DISK
4mm E-CLIP 4pcs M3x3mm SET SCREW 2pcs M3x10mm SCREW 2pcs 3x10mm T/P SCREW 2pcs
2x10mm PIN
