Tech Nitro - 28
19
T0660.093 FLY WHEEL 1pcs
T0660.215 5 mm PILOT SHAFT 1pcs
T06660.096 5x8mm ROLLER BEARING 1pcs
MA 601 FUEL TUBING 100 CM
T0660.100
AIR-FILTER
T0660.086 M3x8 FLAT HEAD SCREWS 4pcs
T0660.087 ENGINE MOUNTS 2pcs
T0660.226 TUNED PIPE & MANIFOLD SET
T0660.088 STD MUFFLER SET
T0660.090 CLUTCH SHOES WITH SPRING
T0660.208 2-SPEED CLUTCH BELL
4mm E-CLIP
M3x25mm SCREW
M3x10mm SCREW
T0660.086
M3x8 FLAT
HEAD
SCREWS
T0660.093
FLY WHEEL
T0660.215
5 mm
PI LOT
SHAFT
MA 601 FUEL TUBING
M3x10mm SCREW
T0660.087
ENGINE
MOUNTS
T0660.208
4mm E-CLIP
T0660.090
CLUTCH
SHOES
WITH
SPRING
T0660.100 AIR-FILTER 1pcs
T0600.062 5x10x4mm
BALL BEARING
T0600.062
5x10x4mm
BALL BEAR-
ING
M3x25mm SCREW
T0660.226 TUNED
PIPE & MANIFOLD
SET
Adjust gear mesh so that the gears move freely but without an
excessive amount of play. If there is too much play you can
damage the gears.
5x11m WASHER
