Multifunction
Analogue
Multimeter User Manual
QM1020
Thank you for purchasing this Multifunction Analogue Multimeter. This
multimeter is perfect for those who prefer to use a galvanometer (analogue
moving coil meter) to take measurements. It can sometimes be more
convenient to view an analogue dial over a digital display when values are
uctuating too. The 90 x 70mm display area ensures the printed, continuous
scale is easy to read. With fuse and diode protection, 20 ranges and a
protective rubber case - this multimeter is great for any level of experience.
Please familiarise yourself with the functions of the multimeter before use. We
recommend retaining this manual for ease of reference.
• Improper use of this meter can cause damage, shock, injury or death.
• Always remove the test leads before replacing the battery or fuses.
• Before using the meter, please inspect the condition of the test leads and the
meter itself for any damage. If damage is present, please discontinue use.
• Do not measure voltage if the voltage on the terminals exceeds 1000V above
earth ground.
• Use great care if voltages are greater than 30VAC RMS. Anything above this
is considered a shock hazard.
• Always discharge capacitors and disconnect power before performing diode,
resistance or continuity tests.
• Remove the batteries from the meter if it will be unused for an extended
period of time.
