protech QM1594 - Measurement Specifications - Capacitance and Frequency; Capacitance Specifications; Frequency Specifications

16
RANGE RESOLUTION ACCURACY
5Hz 0.001Hz
±(1.2% reading + 3 digits)
50kHz 0.01Hz
500kHz 0.1Hz
5kHz 1Hz
50kHz 10Hz
500kHz 100Hz
10MHz 1kHz ±(1.5% reading + 4 digits)
FREQUENCY
Input Protection: 250VDC or 250VAC RMS.
Sensitivity: >0.5V RMS while ≤1MHz, >3V RMS while >1MHz.
RANGE RESOLUTION ACCURACY
50nF 10pF ±(5.0% reading + 7 digits)
500nF 0.1nF
±(3.0% reading + 5 digits)5µF 1nF
50µF 10nF
100µF 0.1µF ±(4.0% reading + 5 digits)
CAPACITANCE
Input Protection: 600VDC or 600VAC RMS
