protech QM1594 User Manual

15
RANGE RESOLUTION ACCURACY
400µA 0.1µA
±(1.2% reading + 2 digits)
4000µA 1µA
400mA 100µA ±(1.5% reading + 2 digits)
10A 10mA ±(2.0% reading + 5 digits)
AC CURRENT
Overload Protection: 500mA/660V and 10A/600V fuse.
Frequency Range: 50~400Hz.
Maximum Inputs: 400mA AC RMS on µA/mA ranges, 10A AC RMS on 10A
range. Autoranging for µA and mA ranges.
RESISTANCE
Overload Protection: 15 seconds maximum 250VDC or 250VAC RMS on all
ranges. Max. Open Circuit Voltage: 2.8V
RANGE RESOLUTION ACCURACY
400Ω 0.1Ω ±(1.5% reading + 4 digits)
4kΩ 1Ω
± (1.5% reading + 2 digits)40kΩ 10Ω
400kΩ 100Ω
4MΩ 10kΩ ± (2.0% reading + 2 digits)
40MΩ 1MΩ ± (2.5% reading + 2 digits)
