16
Wrapped machine can be stored in a dry wareh-
ouse without heating, where the temperature
does not go below -5°C. Unwrapped machine can
be stored only in a dry warehouse, where the tem-
perature does not go below +5°C and where sud-
den changes of temperature are avoided.
Technical d ata
Type mark CCP 380
Universal motor 230 V~
Particular current load 13 A
Input 2.800 W
Frequency 50/60 Hz
Movable supply H07RN-F
Security 16 A fast safety fuse
Revolutions idle of the power spindle 5.300 1/min
Revolutions idle of the power spindle 5.000 1/min
Cutting speed at particular load 15 m/s
Mutual inclination of the chain reglet 0° - 60°
Weight (without the tool) 16,5 kg
Depth of the cut [Guide reglet 18" (45 cm)] at 0° - 380 mm
at 15° - 360 mm
at 30° - 320 mm
at 45° - 250 mm
at 60° - 170 mm
GB
Noise and vibrations
Volumes were measured in accordance with EN 50 144.
For the below stated volumes of noise emissions the addition of K = 4 dB (A) was used as compensa-
tion for possible measuring mistakes.
Level of acoustic performance when idle 113 dB (A)
Level of acoustic pressure on the measured reference surfaces 100 dB (A)
Weighed value of vibrations affecting hands and arms is
smaller than 4,3 m/s
2
Storage
CCP_380GB.fm Seite 16 Montag, 27. August 2001 2:35 14
