Protool VCP 480 E-L AC User Manual

15
Original instruction
GB
1 Technical data
Dust extractor VCP 260 E / VCP 480 E
Voltage 220 – 240 V
Power consumption 350 – 1200 W
Maximum appliance socket connected load EU
CH
2400 W
1100 W
Max. suction capacity (air), turbine 234 m³/h (3900 l/min)
Max. vacuum, turbine 24000 Pa
Filter surface area 6318 cm²
Suction hose DHC-AS 36 mm × 3.5 m
Length of the net cable 7.5 m
Sound pressure level as per EN 60704-2-1 71 dB (A)
Protection category IP X4
Container capacity VCP 260 E
VCP 480 E
26 l
48 l
Dimensions L × W × H VCP 260 E
VCP 480 E
673 × 365 × 455 mm
673 × 405 × 604 mm
Weight VCP 260 E
VCP 480 E
14.5 kg
16.9 kg
Table of contents
1 Technical data ........................... 15
2 Symbols ................................... 15
3 Operating elements .................... 16
4 Intended use ............................. 16
5 Safety instructions ..................... 16
6 Operation ................................. 17
6.1 Initial operation ......................... 17
6.2 Switch on/off ............................. 17
7 Settings .................................... 18
7.1 Adjusting the hose diameter
(only for dust class M) ................ 18
7.2 Connecting electric power tools .... 18
7.3 Adjusting the suction power ........ 18
7.4 Applying the brake ..................... 18
7.5 Temperature cut-out ................... 18
7.6 Changing the fi lter bag ............... 18
7.7 Changing the disposal bag........... 18
7.8 Volumetric fl ow monitoring .......... 19
8 Working .................................... 19
8.1 AUTOClean - Cleaning the main
fi lter ......................................... 19
8.2 Extracting dry materials .............. 19
8.3 Extracting fl uids ......................... 20
8.4 The antistatic system ................. 20
8.5 After fi nishing work .................... 20
9 Service and maintenance ............ 20
9.1 Changing the fi lter element ......... 21
9.2 Emptying the dust container ........ 21
10 Accessories ............................... 21
10.1 Module slot ............................... 21
10.2 Systainer depot ......................... 21
11 Environmental Protection /
Disposal.................................... 21
12 Warranty .................................. 22
13 Declaration of Conformity ............ 22
2 Symbols
Warning of general danger
Risk of electric shock
Wear a dust mask!
≥ 1 mg/m
3
(dust class L)
≥ 0.1 mg/m
3
(dust class M)
Read the instructions
Not to be included in municipal refuse
► Advice or tip
