Belt tensioner
ART. MSH41142
PRE-ASSEMBLED
Guide pulley arm
- Up -
Guide pulley arm
- Down -
Guide pulley bushing
Washer 2,1x5,5x1
MSH41144
Guide pulley
Ball bearing
4x7x2,5
ART. MSH41070
Ball bearing
4x7x2,5
ART. MSH41070
Hex screw M2x4
ART. MSH41141
where I can nd the parts
