Proxim GigaLink 6221E User Manual

GigaLink 6221e 60 GHz, 125 Mbps, 100BASE-FX,
Integral Patch Array Antenna for short ranges
(Part# 605-906221-101)
57.05 to 64 GHz
125 Mbps
20 to 430 m (65 to 1,410 ft)
10 mW
29 dBi Integral Patch Array
3.5 degrees
L-Bracket and Gimbal for 2.5 in and 4 in diameter mast
OD Pipe or Wall Mount
MMF 1310 nm version, compatible with
100 Base-FX, FC Connectors
10 Base-T, RJ-45 Modular (with adapter cable)
10 Base-T, RJ-45 Modular (with adapter cable)
NEMA 5-15P
-20° to 60°C
-30° to 85°C
95% (non-condensing)
94 to 264 VAC, 50/60 Hz
0.85 Amp
85 Watts
Lap-top based software provided
SNMP v1
2 Cartons (each): 17 x 14 x 21 in (431 x 356 x 533 mm)
2 Cartons (each): 28 lbs (12.7 kg)
FCC - Part 15.255 (Cert No. 02700000-30-30)
IC - 4505A-00003030
1 Year on parts and labor
• GigaLink 6221e radio with integral 13 in patch
array antenna (Qty 2)
• AC/DC power module with mounting kit (Qty 2)
• 10BASE-T adapter cable and spare connector
kit (Qty 2)
• Fiber loop-back jumper cable (Qty 2)
• FC/SC adapter cable and SC-SC coupler (Qty 2)
• Mounting L-Bracket for wall/pole mount (Qty 2)
• Pan and Tilt adjustable Gimbal (Qty 2)
• Gigamon software on CD-Rom (Qty 1)
• Field and Installation manual (Qty 1)
DESCRIPTION
FREQUENCY BAND
FULL-DUPLEX
BANDWIDTH
RANGE
1
RF INJECTION POWER
INTO ANTENNA
ANTENNA GAIN
3 DB BEAM WIDTH
MOUNTING
STANDARD MOUNT
INTERFACES
DATA
MANAGEMENT
INSTALLATION
POWER
ENVIRONMENTAL
TEMPERATURE
OPERATING
STORAGE
RELATIVE HUMIDITY
ELECTRICAL
INPUT VOLTAGE
MAX INPUT CURRENT
POWER CONSUMPTION
MANAGEMENT
LOCAL
REMOTE
PHYSICAL
DIMENSIONS
PACKAGED
WEIGHTS
PACKAGED
REGULATORY
ELECTROMAGNETIC
WARRANTY
PACKAGE CONTENTS
PRODUCT MODEL MODEL 6221E MODEL 6421E MODEL 6232E
GigaLink 6421e 60 GHz, 125 Mbps, 100BASE-FX,
Integral 13 in. Parabolic Antenna for medium ranges
(Part# 605-906421-101)
57.05 to 64 GHz
125 Mbps
180 to 1,230 m (590 to 4,035 ft)
8 mW
40 dBi Integral 13 in Parabolic
1.0 degree
L-Bracket and Gimbal for 2.5 in and 4 in diameter mast
OD Pipe or Wall Mount
MMF 1310 nm version, compatible with
100 Base-FX, FC Connectors
10 Base-T, RJ-45 Modular (with adapter cable)
10 Base-T, RJ-45 Modular (with adapter cable)
NEMA 5-15P
-20° to 60°C
-30° to 85°C
95% (non-condensing)
94 to 264 VAC, 50/60 Hz
0.85 Amp
85 Watts
Lap-top based software provided
SNMP v1
2 Cartons (each): 18 x 20 x 21 in (457 x 508 x 533 mm)
2 Cartons (each): 39 lbs (17.7 kg)
FCC - Part 15.255 (Cert No. 02700000-30-30)
IC - 4505A-00003030
1 Year on parts and labor
• GigaLink 6421e radio with integral 13 in
parabolic antenna (Qty 2)
• AC/DC power module with mounting kit (Qty 2)
• 10BASE-T adapter cable and spare connector
kit (Qty 2)
• Fiber loop-back jumper cable (Qty 2)
• FC/SC adapter cable and SC-SC coupler (Qty 2)
• Mounting L-Bracket for wall/pole mount (Qty 2)
• Pan and Tilt adjustable Gimbal (Qty 2)
• Gigamon software on CD-Rom (Qty 1)
• Field and Installation manual (Qty 1)
1
Under ideal operating conditions; Maximum Range at 99.9% availability, Crane Rain Region D2.
See Maximum Link Range chart at www.proxim.com/products/gigalink
GigaLink 6232e 60 GHz, 155 Mbps, OC3-STM1,
Integral Patch Array Antenna for short ranges
(Part# 605-906232-101)
57.05 to 64 GHz
155 Mbps
20 to 415 m (65 to 1,361 ft)
10 mW
29 dBi Integral 13 in Patch Antenna Array
3.5 degrees
L-Bracket and Gimbal for 2.5 in and 4 in diameter mast
OD Pipe or Wall Mount
MMF 1310 nm, compatible with SDH-1,
STM-1 and OC-3, FC Connectors
10 Base-T, RJ-45 Modular (with adapter cable)
10 Base-T, RJ-45 Modular (with adapter cable)
NEMA 5-15P
-20° to 60°C
-30° to 85°C
95% (non-condensing)
94 to 264 VAC, 50/60 Hz
0.85 Amp
85 Watts
Lap-top based software provided
SNMP v1
2 Cartons (each): 17 x 14 x 21 in (431 x 356 x 533 mm)
2 Cartons (each): 28 lbs (12.7 kg)
FCC - Part 15.255 (Cert No. 02700000-30-30)
IC - 4505A-00003030
1 Year on parts and labor
• GigaLink 6232e radio with integral 13 in patch
array antenna (Qty 2)
• AC/DC power module with mounting kit (Qty 2)
• 10BASE-T adapter cable and spare connector
kit (Qty 2)
• Fiber loop-back jumper cable (Qty 2)
• FC/SC adapter cable and SC-SC coupler (Qty 2)
• Mounting L-Bracket for wall/pole mount (Qty 2)
• Pan and Tilt adjustable Gimbal (Qty 2)
• Gigamon software on CD-Rom (Qty 1)
• Field and Installation manual (Qty 1)
