GigaLink Series Technical Specifications
License free 60 GHz
GigaLink 6432e 60 GHz, 155 Mbps, OC3-STM1,
Integral 13 in. Parabolic Antenna for medium ranges
(Part# 605-906432-101)
57.05 to 64 GHz
155 Mbps
175 to 1,210 m (574 to 3,970 ft)
8 mW
40 dBi Integral 13 in Parabolic
1.0 degree
L-Bracket and Gimbal for 2.5 in and 4 in diameter mast
OD Pipe or Wall Mount
MMF 1310 nm, compatible with SDH-1, STM-1 and
OC-3, FC Connectors
10 Base-T, RJ-45 Modular (with adapter cable)
10 Base-T, RJ-45 Modular (with adapter cable)
NEMA 5-15P
-20° to 60°C
-30° to 85°C
95% (non-condensing)
94 to 264 VAC, 50/60 Hz
0.85 Amp
85 Watts
Lap-top based software provided
SNMP v1
2 Cartons (each): 18 x 20 x 21 in (457 x 508 x 533 mm)
2 Cartons (each): 39 lbs (17.7 kg)
FCC - Part 15.255 (Cert No. 02700000-30-30)
IC - 4505A-00003030
1 Year on parts and labor
• GigaLink 6432e radio with integral 13 in
parabolic antenna (Qty 2)
• AC/DC power module with mounting kit (Qty 2)
• 10BASE-T adapter cable and spare connector
kit (Qty 2)
• Fiber loop-back jumper cable (Qty 2)
• FC/SC adapter cable and SC-SC coupler (Qty 2)
• Mounting L-Bracket for wall/pole mount (Qty 2)
• Pan and Tilt adjustable Gimbal (Qty 2)
• Gigamon software on CD-Rom (Qty 1)
• Field and Installation manual (Qty 1)
DESCRIPTION
RADIO/SYSTEM SPECS
FREQUENCY BAND
FULL-DUPLEX
BANDWIDTH
RANGE
1
RF INJECTION POWER
INTO ANTENNA
ANTENNA GAIN
3 DB BEAM WIDTH
MOUNTING
STANDARD MOUNT
INTERFACES
DATA
MANAGEMENT
INSTALLATION
POWER
ENVIRONMENTAL
TEMPERATURE
OPERATING
STORAGE
RELATIVE HUMIDITY
ELECTRICAL
INPUT VOLTAGE
MAX INPUT CURRENT
POWER CONSUMPTION
MANAGEMENT
LOCAL
REMOTE
PHYSICAL
DIMENSIONS
PACKAGED
WEIGHTS
PACKAGED
REGULATORY
ELECTROMAGNETIC
WARRANTY
PACKAGE CONTENTS
PRODUCT MODEL MODEL 6432E MODEL 6451E-AC / MODEL 6451E-DC MODEL 6651E-AC / MODEL 6651E-DC
GigaLink 6451e-AC 60 GHz link, 1.25 Gbps, 1000SX,
Integral 13 in Parabolic Antenna for short ranges,
AC Power (Part # 605-906451-101)
GigaLink 6451e-DC 60 GHz link, 1.25 Gbps, 1000SX,
Integral 13 in Parabolic Antenna for short ranges,
DC Power (Part# 605-906451-201)
57.05 to 64 GHz
1.25 Gbps
20 to 440 m (66 to 1,430 ft)
8 mW
40 dBi Integral 13 in Parabolic
1.0 degree
Adjustable Precision Azimuth and Elevation Mount
2.75 to 4.5 in OD Pipe Mount only
MMF 850 nm, compatible with 1000 Base-SX,
FC Connectors
100 Base-FX, MMF 1310 nm, FC connector
100 Base-T, RJ-45 Modular (with adapter cable)
MIL-C-5015-type connector (accepts 12 to 16-
AWG three conductor power cable)
-30° to 60°C
-40° to 85°C
95% (non-condensing)
6451e-AC: 100 to 230 VAC, 50/60 GHz;
6451e-DC: -48 VDC nominal (-40 to -57 VDC)
2
6451e-AC: 0.9 to 0.5 Amps; 6451e-DC: 1.2 Amps
90 Watts
Lap-top based software provided
SNMP v1
2 Cartons (each): 18 x 20 x 21 in (457 x 508 x 533 mm)
6451e-AC - 2 Cartons (each): 45 lbs (20.4 kg)
6451e-DC - 2 Cartons (each): 38 lbs (17.2 kg)
FCC - Part 15.255 (FCCID No. 02700001-30-30)
IC - 4505A-00013030
1 Year on parts and labor
• GigaLink 6451e-AC or 6451e-DC radio with
integral 13 in parabolic antenna (Qty 2)
• DC power connector assembly (Qty 2)
• 100 BASE-T adapter cable (Qty 2)
• Fiber loop-back jumper cable (Qty 2)
• FC/SC adapter cable and SC-SC coupler (Qty 2)
• Precision adjustable azimuth and elevation
mount (Qty 2)
• Gigamon software on CD-Rom (Qty 1)
• Field and Installation manual (Qty 1)
• Universal AC Power module with DC cable
assembly included with 6451e-AC (Qty 2)
2
1
Under ideal operating conditions; Maximum Range at 99.9% availability, Crane Rain Region D2. See Maximum Link Range chart at www.proxim.com/products/gigalink
2
DC versions do not include power module. Require -48 VDC power source.
GigaLink 6651e-AC 60 GHz, Link, 1.25 Gbps,
1000SX, Integral 13 in Parabolic Antenna for
medium ranges, AC Power (Part # 605-906651-101)
GigaLink 6651e-DC 60 GHz, Link, 1.25 Gbps,
1000SX, Integral 13 in Parabolic Antenna for
medium ranges, DC Power (Part# 605-906651-201)
57.05 to 64 GHz
1.25 Gbps
300 to 1,142 m (975 to 3,711 ft)
10 mW
41 dBi Integral 13 in Parabolic
0.9 degree
Adjustable Precison Azimuth and Elevation Mount
2.75 to 4.5 in OD Pipe Mount only
MMF 850 nm, compatible with 1000 Base-SX,
FC Connectors
100 Base-FX, MMF 1310 nm, FC connector
100 Base-T, RJ-45 Modular (with adapter cable)
MIL-C-5015-type connector (accepts 12 to 16-
AWG three conductor power cable)
-30° to 60°C
-40° to 85°C
95% (non-condensing)
6651e-AC: 94 to 264 VAC, 50/60 Hz;
6651e-DC: -48 VDC nominal (-40 to -57 VDC)
2
6651e-AC: 0.9 to 0.5 Amps; 6651e-DC: 1.2 Amps
90 Watts
Lap-top based software provided
SNMP v1
2 Cartons (each): 18 x 20 x 21 in (457 x 508 x 533 mm)
6651e-AC - 2 Cartons (each): 45 lbs (20.4 kg)
6651e-DC - 2 Cartons (each): 38 lbs (17.2 kg)
FCC - Part 15.255 (FCCID No. 02700001-30-30)
IC - 4505A-00013030
1 Year on parts and labor
• GigaLink 6651e-AC or 6651e-DC radio with
integral 13 in parabolic antenna (Qty 2)
• DC power connector assembly (Qty 2)
• 10BASE-T adapter cable (Qty 2)
• Fiber loop-back jumper cable (Qty 2)
• FC/SC adapter cable and SC-SC coupler (Qty 2)
• Mount arm and associated hardware (Qty 2)
• Pole-Mounted gimbal (Qty 2)
• Gigamon software on CD-Rom (Qty 1)
• Field and Installation manual (Qty 1)
• Universal AC Power module with DC cable assembly -
included with Model 6651e-AC only (Qty 2)
2
