Owner’s Reference Stellar S300 and M700 Amplifiers
2
1 2 3 4 5 6 7 8 9 10
1
2
3
4
5
6
7
8
Main Power Switch
AC Power Input
Negative Speaker Output
Positive Speaker Output
Negative Speaker Output
Positive Speaker Output
5 Volt - 12 Volt Trigger Input
5 Volt - 12 Volt Trigger Output
9
Single Ended Input
Balanced Input
10
Stellar M700 Mono Amplifier
Rear Panel View
