RFID programming instructions
Activating the programming card
Initializing / activating a programming card (Who is the boss in future?)
1.Press the push-button on the rear side
2.The lock will make a ticking sound (signal). Hold the programming card on the lock within 3 seconds of hearing
this signal.
3.Two short ascending tones will confirm that the programming card has been saved successfully.
Initializing a key
Initializing the key card or chip key
1.Please place the programming card onto the lock.
2.The lock will make a ticking sound (signal). Place the key card or chip key onto the lock within 3 seconds of
hearing this signal.
3.Two short ascending tones will confirm that initialization was successful.
4.The lock can now be opened using the key card or the chip key.
Deleting the key card or chip key
1.Please place the programming card onto the lock.
2.The lock will make a ticking sound (signal). Place the key card or chip key onto the lock within 3 seconds of
hearing this signal.
3.Two short ascending tones will confirm that deletion was successful.
Delete all keys
To delete all keys at once, place the programming card onto the lock for several seconds.
Accessories
3050 - Battery
The 3 volt lithium battery has life-span of
10 years with the 125 KHz and 3 years with
the 13,56 MHz technology. The battery has
enough power to open the lock more than
30,000 times. When the battery starts to
run out, the lock will not longer lock and a
continuous tone will sound for 15 seconds,
at this point change the battery.
Metal kit
With a stamp in the metal door, the inter-
nal antenna of the SOLO and SOLO13 lock
will work through the metal door.
3060 glass set
This set is similar with the metal kit and consists of
an additional adhesive glue tape. Depending on the
where the force is applied, the double-sided sticky
tape on an untreated surface will hold up to 25 kg or
45 kg (55lbs or 99lbs), depending on the direction of
pull.
3051s - External power supply
The cable is 1.5 m long and can be
plugged directly into the lock. Each con-
verter can supply a maximum of 5 locks.
Never use transformers and batteries at
the same time!x 5 mm
3053s - Spacer plate
A square shaped spacer plate to prevent
cables from being crushed. Measure-
ments: 60 x 60 x 5 mm
Accessories
3040s - external antenna (125 KHz)
The flat external antenna is used
whenever the distance from the key is
greater than 25 mm or if the lock is
fixed onto a rear panel. Cable: 1,5m
3041 - round mini antenna (125
KHz)
With a hole of 7,5mm diameter, this
round mini antenna can be placed in
several variations.
3010 - Programming card
This card can be used to give or deny ac-
cess as well as to change the software
settings. The same programming card
can be assigned to multiple locks within a
shop / area for example.
3030 - Key card
The range is approx. 30 mm cross wood
or glass. Program up to 50 different keys
per lock.
3020 – Chip key
This chip key is extremely small with a
diameter of approx. 30 mm. It can be eas-
ily attached to a key ring. The maximum
range is 20 mm.
