EC1309V2
User Guide 1 EC1309V2
4
No. Name Description
2
Port for connecting to S-Video input port of a
TV.
3
Port for connecting to Composite video input
port of a TV.
4
Port for connecting to left audio channel input
port of a TV.
5
Port for connecting to right audio channel
input port of a TV.
6
10/100M Base-T port for connecting to service
provider’s Ethernet port on wall or on xDSL
modem.
7 DC input port (DC 12V 1A).
8
Power switch.
