User Manual GB
Setting the gears (model with 3-gear hub)
Installation of gear stick
Figure 10: Take the gear stick out of the poly
bag and insert it into the right side of the rear
axle (in driving direction) until it stops at the
black spring.
Figure 11: Then you can mount the gearbox
onto the rear axle and tighten it with a 5 mm
Allen key (3-5 Nm.)
No further settings need to be made to the
gearbox.
Setting the derailleur gears
(models with derailleur gear hub)
1. Setting the limiter for the hardest gear
Rotate the upper setting screw in such a way
that, looking from the rear, the guide roller is
parallel to the contour line of the smallest gear.
2. Setting the limiter for the easiest gear
Rotate the lower setting screw in such a way
that the guide roller is in position along the
largest gear.
3. Setting the tension
Carry out fine adjustments of the gear posi-
tions by turning the tension setting screw.
Rotating anti-clockwise eases switching to the
next largest gear. Rotating clockwise eases
switching to the next smallest gear.
(A) Konturlinie des kleinsten Ritzels
(A) Contour line of the smallest gear
(B) Guide roller
(C) Upper setting screw
(A) Setting screw
for tension
(A) Largest gear
(B) Guide roller
(C) Lower setting screw
