10
Go-Cart
Fig. 1: Insert and mount the twin seat
strut in the plastic holder.
Fig. 2: Apply the front apron and press it down.
Fig. 3: Check that the front apron
is rmly tted.
Both hooks must engage rmly on
the front axle carrier (>>click<<).
Fig. 4: Press the insert into the front apron.
The four hooks must en-
gage rmly (>>click<<).
Fig. 5: Grease the steering column.
Fig. 6: Insert the steering column from
below a little way through the front
axle carrier whilst tilting it slightly.
Fig. 7: Insert the plastic sleeve and washer
onto the steering column up to the
stop (lug / protrusion in the front axle
carrier) and press them in there.
Fig. 8: Tilt the steering column upwards
again and push it through the
front apron and the seat strut.
Apply the large washer onto the
hook. Ensure correct t of the plas-
tic sleeve and washer in the stop.
Fig. 9: Put on and mount the steering wheel.
Only tighten the screw until the
steering wheel does not wobble.
Excessive tightening can cause
damage to the steering.
Fig. 10: Apply the seat claw and the seat, and
screw the turning handle on tightly.
The seat claw must engage in the per-
foration in the twin seat strut (below).
Operation
Fig. 11: Adjust the seat position.
Fig. 12: Use the brake to reduce
speed or to stop.
Fig. 13: Retighten the chain.
Fig. 14: Open the chain guard
(grease or replace the chain).
