The delivery consists of (Fig. A):
1. Vehicle chassis (inc. axles, wheels,
drive unit, chain guard, brake)
2. Seat
3. Seat twin strut
4. Steering wheel
5. Steering column
6. Front apron
7. Separate insert for xing in the front apron
8. Fixing material (polythene bag)
9. Steering wheel cover (polythene bag)
10. Seat claw and toggle for x-
ing the seat (polythene bag)
Assembly
The assembly guidelines are located on
the last pages of these instructions.
You require the following tools
for assembly (Fig. B):
1. Open end wrench 10mm
2. Open end wrench 13mm
3. Allen wrench 4mm
Small parts required during assembly (for
example screws and washers) must not come
into the hands of small children. There is a
risk of suffocation through swallowing. Keep
any packaging material away from children.
The product must be assembled carefully
by an adult in order to prevent accidents or
injuries occurring due to false assembly.
Please allow yourself sufcient time.
Some of this assembly work requires skill
and practice in working with tools (e.g.
wrenches). If uncertain, please contact
your specialist retailer or a workshop.
At several points it is necessary to tighten the
screws with a certain force. This force is stated
in Newton metres (for example 2 Nm). If a
screw is tightened with too little force, the con-
nection may be too loose and therefore un-
safe. If the force used is too high, screws and
other parts may be damaged and destroyed.
