Pulsar 5000 series User Manual

* DO NOT ALLOW CONTACT WITH SKIN
If it is suspected that an instrument has been subjected to temperatures in
excess of +400°C
* CONTACT OUR SALES OR SERVICE DEPARTMENT TO
ASCERTAIN IF THE INSTRUMENT CONTAINS VITON
W A R N I N G
ELECTRICAL CONNECTIONS
4-20MA VOLTAGE
IN+ IN- EARTH IN+ COM OUT+ EARTH
CABLE R BL DRAIN
R W Y DRAIN
CONNECTOR 1 2 E 1 2 3 E
OUTPUT SUPPLY VOLTAGE
4-20mA 9 - 35V d.c.
0.5 - 5.5V d.c. 7.5 - 35V d.c.
1 - 6V d.c. 8 - 35V d.c.
0 - 5V d.c. 7.5 - 35V d.c.
0.1 - 5.1V d.c. 7.5 - 35V d.c.
1 - 5V d.c. 7.5 - 35V d.c.
