Pulsar Chromabatten Series User Manual

ChromaZone
TM
Software Version 4.0
Pulsar ChromaZone / ChromaBank / ChromaFlood / ChromaBatten Software Version No. 4.0 (MAIN micro 4.0
09-09-05 or later + UIM micro 1.0 07-03-05 or later ) has many exciting features.• Two built in Chases – allowing
superimposition of effects and crossfading between chases. Chase 1 and 2 use the same table of 31 chases but
there are differences to give you more choice - Chase 1 uses the ALL Red, Green and Blue Channels, 1, 2 & 3, to
change the colour of some chases (see table) while Chase 2 stays white and uses them to give a background colour.
The chases have a very wide range of speeds.
• 7 operating modes: 3, 6, 9, 10, 36, 42 and 46 Channel Modes.
• A Master Dimmer Channel (Ch.10) for the 36 individual RGB channels, which may become a Global Grand Master
for the All R/G/B and Chases Levels too.
• Input Smoothing may be disabled for fast display of video graphics and video frame rate capability.
• Please see the Channel Assignments Table page for details of the Operating Modes and how to select them,
Channel Listings, and further information.
Chase % Bit Chase Notes
No. Input No. Description
15 100 255 Auto Chase
95 244 Green Yellow Red Bar Graph Reverse Use Channel1
92 236 Green Yellow Red Bar Graph Forward Use Channel1
14 89 228 Rainbow Strobe
13 86 220 White / Any Colour Strobe Channels 1, 2 & 3 set colour
83 212 White / Any Colour Crossover Channels 1, 2 & 3 set colour
12 80 204 Blue-Yellow Wave Reverse
77 196 Blue-Yellow Wave Forward
73 188 Green-Magenta Wave Reverse
11 70 180 Green-Magenta Wave Forward
67 172 Red-Cyan / AnyCol/Op.Col Wave Forward
10 64 164 Red-Cyan / AnyCol/Op.Col Wave Reverse
Channels 1, 2 & 3 set colour
All 3 at 0% = Red-Cyan
9 61 156 Black-White/AnyColour Wave Forward
58 148 Black-White/AnyColour Wave Reverse
Channels 1, 2 & 3 set colour
All 3 at 0% = White.
8 55 140 Random Cols. Chase1 Crossfade, Chase2 Snap
52 132 Rainbow 2 Crossfade Forward
48 124 Rainbow 2 Crossfade Reverse
Wider primary colours to
compensate for extra diffusion
7 45 116 Rainbow Crossfade Forward
6 42 108 Rainbow Crossfade Reverse
Equal width primary &
secondary colours
39 100 “Follow 3” 18 Contrasting Colours Reverse
5 36 92 “Follow 3” 18 Contrasting Colours Forward
33 84 18 Crossfading Colours Reverse
4 30 76 18 Crossfading Colours Forward
27 68 White/AnyColour/AutoColour Cascade Reverse
23 60 White/AnyColour/AutoColour Cascade Forward
Channels 1, 2 & 3 set colour.
All 3 at 0% = White.
All 3 at 100%
=
Auto Colour Change
3 20 52 6 Crossfading Pastel Colours
17 44 Colour Wipes
2 14 36 6 Crossfading Colours
1 11 28 6 Separate Colours
8 20 Red Green Blue Bar Graphs Reverse Use Channels 1, 2 & 3
5 12 Red Green Blue Bar Graphs Forward Use Channels 1, 2 & 3
0 0 0 No Chase
