Stand Alone Settings View/Change (continued)
To View/Change the Stand Alone Settings, press the ñ or ò keys
on the UIM until the display shows Stand Alone Settings
View/Change.
Press the X (change) key on the UIM, then select the channel to
view/change using the ï or ð keys. These keys repeat if held
down. When the channel to be viewed/changed is showing in the
display, press the ñ or ò keys to change the value. These keys
repeat if held down. The display shows both the bit number (0-255)
and percentage (0-100%).
Please see the Chase Select Table when modifying chases.
To modify further channels, select the channel to view/change using
the ï or ð repeat keys, pressing the ñ or ò repeat keys to
change the value.
When you have finished modifying channels, press the ü (Yes) key
to save changes or X (Back) key to restore the previous settings.
? VIEW(Sig)/SET(NoSig) Chan Levels
To View the Channel Levels/Change the Stand Alone Settings, press
the ñ or ò keys on the UIM until the display shows
VIEW(Sig)/SET(NoSig) Chan Levels
Press the X (change) key on the UIM, then select the channel to
change/view using the ï or ð keys. These keys repeat if held
down.
When the channel to be changed/viewed is showing in the display,
press the ñ or ò keys to change the value. These keys repeat if
held down. The display shows both percentage (0-100%) and bit
number (0-255), and for channels 4 (Chase 1 Select) and 7 (Chase 2
Select) the chases selected.
Please see the Chase Select Table when modifying chases.
Notes:
• this menu item is for this session use only, data is never saved.
• the values can only be changed if the unit is not receiving data.
• pressing the X or ü keys returns to the main menu.
? Restore Factory Default Settings
To restore the factory default settings, press the ñ or ò keys on the
UIM until the display shows Restore Factory Default Settings.
Press the X (change) key on the UIM, then press the ü (Yes) key to
restore defaults or X (Back) key to exit.
The factory default settings are
DMX Address 1
ChromaZone Mode 46 Channel
Channels per Fixture 3 (CFLD) / 9(CBAT)
Fixture number 1
Chase patterns 12 Way
Channel 10 Grand Master for the 36 RGBs only
Input Smoothing ON
Low Voltage Supply ON
DMX Line Termination OFF
If NoSignal use: Stand Alone Mode
Stand Alone Settings Ch.1 – 3 = 0 bits / 0%
Ch.4 = Chase 1 Select = Auto Chase
Ch.5 = Chase 1 Speed = 128 bits / 50%
Ch.6 = Chase 1 Level = 255 bits / 100%
Ch.7 – 46 = 0 bits / 0%
Failure of the internal ChromaFlood or ChromaBatten 5 Amp,
5x20mm Power Supply Fuse, usually indicates an internal fault
requiring servicing by a qualified engineer.
If the front glass becomes cracked or broken, disconnect from the
mains immediately and have the unit repaired. Replacement glasses
are available from Pulsar.
The PMX/DMX connections (input and thru) are protected against
inadvertent shorts to 240Vac and static damage.
PORTABLE APPLIANCE TESTING - The Pulsar
ChromaFlood and ChromaBatten may be safely Earth Bond and
Insulation Tested.
STANDARDS - The Pulsar ChromaFlood and ChromaBatten
comply with the following International and National Standards:
Electrical Safety - IEC65, EN60065, BS415
EMC - EN50081-1, EN55022, EN50082-1
Index of Protection – IP65
Marking Directive 93/68/EEC - The Pulsar
ChromaFlood and ChromaBatten both meet the
EMC Directive 89/336/EEC and the Low Voltage
Directive 73/23/EEC.
Conforms to: ANSI/UL Standard 6500
Certified to: CAN/CSA-E60065-00
GUARANTEE - 12 months from the date of original purchase. The
guarantee is limited to parts and labour. The guarantee is void if the
unit is misused, the cable connections are not in a dry environment or
made using an IP68 rated connector, or unauthorised persons
perform repairs. In the unlikely event of a fault occurring, do not use
without repair. Return the unit to your supplier with a description of
the fault, or direct to Pulsar for immediate attention
DIMENSIONS AND WEIGHTS
Code Unit Width
Height
Depth
Weight
mm mm mm kg
CFLD200
ChromaFlood200
365.0
373.0
118.0
8.0
CBAT200 ChromaBatten200 1198.0
132.0
132.0
12.4
