Pulsar Chromaflood CFLD200 - Channel Assignments Tables; 3, 6, 9, and 10 Channel Modes; 36, 42, and 46 Channel Modes

Pulsar Light of Cambridge Limited ? 3 Coldhams Business Park ? Norman Way ? Cambridge ? CB1 3LH ? England ? Tel: 44 (0)1223 403500 ? Fax: 44 (0)1223 403501 ? Email: sales@pulsarlight.com ? Web: www.pulsarlight.com
36 Channel Mode
3 Ch
annels
/
Fixture
6
Ch
annels
/
Fixture
9
Ch
annels
/
Fixture
1 Fixture 1 Red 1 Fixture 1 Red 1 1 Fixture 1 Red 1
2 Fixture 1 Green 2 Fixture 1 Green 1 2 Fixture 1 Green 1
3 Fixture 1 Blue 3 Fixture 1 Blue 1 3 Fixture 1 Blue 1
4 Fixture 2 Red 4 Fixture 1 Red 2 4 Fixture 1 Red 2
5 Fixture 2 Green 5 Fixture 1 Green 2 5 Fixture 1 Green 2
6 Fixture 2 Blue 6 Fixture 1 Blue 2 6 Fixture 1 Blue 2
36 Fixture 12 Blue 36 Fixture 6 Blue 2 36 Fixture 4 Blue 3
42 Channel Mode
3 Ch
an
nels
/
Fixture
6
Ch
annels
/
Fixture
9
Ch
annels
/
Fixture
1-6 as 6 Channel Mode 1-6 as 6 Channel Mode 1-6 as 6 Channel Mode
7 Fixture 1 Red 7 Fixture 1 Red 1 7 Fixture 1 Red 1
8 Fixture 1 Green 8 Fixture 1 Green 1 8 Fixture 1 Green1
9 Fixture 1 Blue 9 Fixture 1 Blue 1 9 Fixture 1 Blue 1
10 Fixture 2 Red 10 Fixture 1 Red 2 10 Fixture 1 Red 2
11 Fixture 2 Green 11 Fixture 1 Green 2 11 Fixture 1 Green 2
12 Fixture 2 Blue 12 Fixture 1 Blue 2 12 Fixture 1 Blue 2
42 Fixture 12 Blue 42 Fixture 6 Blue 2 42 Fixture 4 Blue 3
46 Channel Mode
3 Ch
annels
/
Fixture
6
Ch
annels
/
Fixture
9
Ch
annels
/
Fixture
1-9 as 9 Channel Mode 1-9 as 9 Channel Mode 1-9 as 9 Channel Mode
10 36xRGBGrand Master 10 36xRGB Grand Master 10 36xRGB Grand Master
OR OR OR
10 Global Grand Master 10 Global Grand Master 10 Global Grand Master
11 Fixture 1 Red 11 Fixture 1 Red 1 11 Fixture 1 Red 1
12 Fixture 1 Green 12 Fixture 1 Green 1 12 Fixture 1 Green 1
13 Fixture 1 Blue 13 Fixture 1 Blue 1 13 Fixture 1 Blue 1
14 Fixture 2 Red 14 Fixture 2 Red 2 14 Fixture 1 Red 2
15 Fixture 2 Green 15 Fixture 2 Green 2 15 Fixture 1 Green 2
16 Fixture 2 Blue 16 Fixture 2 Blue 2 16 Fixture 1 Blue 2
46 Fixture 12 Blue 46 Fixture 6 Blue 2 46 Fixture 4 Blue 3
3
Channel Mode
1 All Red
2 All Green
3 All Blue
6 Channel Mode
1 All Red
2 All Green
3 All Blue
4 Chase Select (see Chase Table)
5 Chase Speed
6 Chase Level
9
Channel Mod
e
1 All Red
2 All Green
3 All Blue
4 Chase1 Select (see Chase Table)
5 Chase1 Speed
6 Chase1 Level
7 Chase2 Select (see Chase Table)
8 Chase2 Speed
9 Chase2 Level
10 Channel Mod
e
1 All Red
2 All Green
3 All Blue
4 Chase1 Select (see Chase Table)
5 Chase1 Speed
6 Chase1 Level
7 Chase2 Select (see Chase Table)
8 Chase2 Speed
9 Chase2 Level
10 Global Grand Master
CHROMAFLOOD AND CHROMABATTEN
CHANNEL ASSIGNMENTS TABLES
