Discrete Digital Zoom
13
The riflescope allows you to quickly increase the basic magnification (please refer
to the “Digital zoom” line in the specifications table) by two times or four times, as
well as to return to the basic magnification. To operate the discrete digital zoom,
press successively the DOWN (10) button.
Quick Menu
14
The Quick menu allows to manage basic riflescope’s settings (display
brightness and contrast, continuous digital zoom, stadiametric
rangefinder) and change zeroing distance (if several are available) in the
current shooting profile.
џ Enter the quick menu with a brief press of the М (9) button.
џ To toggle between the functions below, press briefly the M button.
џ To exit the quick menu press and hold down the М button.
џ Automatic exit takes place in 3 sec of inactivity (controls are not used).
Brightness – press briefly the UP (8) and DOWN (10) buttons to change display
brightness from 00 to 20.
Contrast - press briefly the UP (8) and DOWN (10) buttons to change display
contrast from 00 to 20.
Continuous Digital zoom - press briefly the UP (8) and DOWN (10) buttons to
change digital zoom value from 1.0 to 4.0. Change step for digital zoom is 0.1.
џ Initial continuous digital zoom value is x1.0 if digital zoom is not active.
џ Initial continuous digital zoom value is х2.0 if digital zoom is 2x;
џ Initial continuous digital zoom value is х4.0 if digital zoom is 4x.
џ Notes. Full magnification is the product of the basic magnification value and
continuous digital zoom value. For example: the riflescope's basic magnification
is 4.5х, continuous digital zoom value х2.7. Full magnification is 12.1x (4.5*2.7).
Display brightness and contrast settings are saved in the memory when the unit
is turned off.
The stadiametric rangefinder — press the UP/ DOWN buttons to change
distance to an object being ranged (please refer to section 20 for more details).
Information on the actual profile and zeroing distance A100 , at which zeroing
was done in this profile (for example, profile A, zeroing distance 100m).
џ Toggle between available combination of profile and distance (if there are more
than one) zeroing distances with the UP (8) and DOWN (10) buttons.
џ This information is also shown in the status bar.
04
Main Menu
15
џ Enter the main menu with a long press of the М (9) button.
џ Press the UP (8) and DOWN (10) buttons to toggle between the main menu
options.
џ Main menu navigation is cyclical: as soon as the last menu option of the first tab
is reached, first menu option of the second tab starts.
џ Enter a submenu of the main menu with a brief press of the М button.
џ Exit the submenu with a long press of the М button.
џ Exit the main menu with a long press of the М button.
џ Automatic exit takes place in 10 sec of inactivity.
џ Upon exit from the menu the cursor location is memorized only for the duration
of the working session (i.e. until the unit is turned off). Upon restarting the
riflescope and entering the menu the cursor will be located on the first menu
option.
MENU STRUCTURE
The menu includes two tabs. To toggle between the tabs, press the UP (8) and
DOWN (10) navigation buttons – when the last menu option of the M1 tab is reached,
you move to the first menu option of the M2 tab and viceversa.
Wi-Fi settings
Zeroing profile
Reticle setup
Zeroing
10
Owner
Graphics brightness
Guest
Menu
Settings
Device information
Microphone
Sensors
Language
Date
Time
Reset
Format
Unit of
measuremen
Menu
Off
Tab 1
Tab 2
