Pulsar DTS-i 220 - Technical Specifications

Location of Parts : Speedometer Indicators Technical Specifications
Engine : 4 Stroke, Single Cyl.,
Natural air/ Oil cooled
Bore x Stroke : 67.00mm x 62.4mm
Engine Displacement : 220 cc
Compression Ratio : 9.5 + 0.5 : 1
Idling Speed : 1400 + 100
Max. Net Power : 21 PS at 8500 rpm.
Max. Net Torque : 19.12 Nm at 7000 rpm.
Ignition System : Digital CDI
Spark Plug : 2 Nos. Champion
RG6HCC
Spark Plug Gap : 0.8 to 0.9 mm
Lubrication : Wet sump, Forced
Transmission : 5 speed constant mesh
Brakes (Frt. & Rr.) : Hydraulic operated disc
brakes
Fuel Tank Capacity :
Full : 15.0 liters
Reserve : 3.2 liters
Usable Reserve : 2.0 liters
Tubeless Tyre Size :
Front : 90/90 x 17,49P
Rear : 120/80 x 17, 61P
Tyre Pressure :
Front : 2kg / cm2 (28 PSI)
Rear (solo) : 2 kg / cm2 (28 PSI)
Rear (pillion) : 2.25 kg / cm2 (32 PSI)
Dimensions :
Length : 2035 mm
Width : 750 mm
Height : 1165 mm
Wheel base : 1350 mm
Min. Turning Radius : 2500 mm
Ground Clearance : 165 mm (Min.)
Electrical System : 12 Volts DC
Head Lamp : 55/55 W-H7 (for F)
: 35/35 W (for S)
Pilot Lamp : 5 W Each 2 Nos.
Tail /Stop : LED/LED
Turn Signal Indi. : 10 W - 12 V
Neutral Indicator : LED
Hi Beam Indicator : LED
Turn Pilot Indicator : LED
Side Stand Indi. : LED
Speedometer : LCD Display
Rear No. Plate : 5 W
Horn : 12 V DC (2 Nos.)
Battery : 12V - 9 Ah
Vehicle Kerb Wt. : 152 kg. (for F)
: 148 kg. (for S)
Gross Vehicle Wt. : 282 kg. (for F)
: 278 kg. (for S)
Climbing Ability : 28% (160max)
Note : All dimensions are under UNLADEN condition. Above information is subject to change.
1. Side stand indicator : When Side stand is ‘ON’, the Side stand indicator will be lit.
2. Turn signal indicator : When turn signal switch is turned to LH/RH, pilot indicator flash.
3. Trip meter : It shows the distance travelled since it was last reset to zero.
4. Trip meter knob : Reset trip meter to zero by pressing the trip meter knob.
5. Speedometer : The vehicle speed is displayed digitally.
6. Odometer : The Odometer shows the total distance that the vehicle has accumulated.
7. Fuel level indicator : Fuel level indicator shows available fuel in fuel tank.
8. Tachometer : It shows the engine speed in RPM.
9. Neutral indicator : When the transmission is in neutral, the neutral indicator light will lit.
10. Hi beam indicator : When the H/L is on high beam, the hi beam indicator light will lit.
5
1
6
3
10
9
2
4
8
7
1
2
