DIGITAL DMX 512 OUTPUT - 512 DMX slots or 216 PMX
channels are transmitted. If the patch is off (patch on/off
information is transferred with card data), the 216 PMX channel
levels are transmitted as DMX slots. If the patch is on, then
512 DMX slots are transmitted using the PMX to DMX patch
map information transferred with the card. DMX slots are
transmitted in a serial digital format complying with the
DMX512 and DMX512/1990 standards.
The pin connections are:
Pin 1 = Screen - Chassis Earth
Pin 2 = Signal -
Pin 3 = Signal +
Pins 4&5 = not used
Please use twin core screened cable and ensure that the end
of the DMX line is terminated with a resistor of 100-120 ohms
between Signal + and Signal -. A DMX line must not be split or
branched without the use of a purpose built splitter unit. A
PMX (Pulsar MultipleX) line does not need terminating and can
be branched or split.
FUSES AND PRECAUTIONS
MAINS FUSE - The Mains Fuse is mounted on the front
panel of the Replay Unit. The fuse is a F 1A L 5x20mm Glass
fuse. Do NOT use any other type of fuse. Failure indicates an
internal fault and servicing by a qualified engineer will be
required.
INSTALLATION AND VENTILATION - The Replay Unit
consumes very little power, therefore ventilation around the
unit is not required, and several units may be stacked together.
OTHER INFORMATION
MAINS CABLE REPLACEMENT - This
modification should only be carried out by suitably
skilled and competent persons.
Important - the earth wire must be longer than the live and
neutral wires so that the earth will always be the last wire to
come off if the cable is pulled from the unit. Ensure the outer
sheath covering the live and neutral wires is within 15mm of
the live and neutral tags on the PCB.
AUDIO INPUTS - These are not earthed directly within the
unit but through a resistor, this eliminates earth loops and
hence hum and interference on your sound equipment.
PORTABLE APPLIANCE TESTING - The Replay Unit
may be safely Earth Bond and Insulation (500V) tested.
STANDARDS - The Replay Unit complies with the following
International and National Standards:
Electrical Safety - IEC65, EN60065, BS415
EMC - EN50081-1, EN55022, EN50082-1
Rack Mounting - IEC297
Index of Protection - IP30
Marking Directive 93/68/EEC - The Replay Unit
meets both the EMC Directive 89/336/EEC and
the Low Voltage Directive 73/23/EEC.
GUARANTEE - 12 Months from the original date of
purchase. The guarantee is limited to parts and labour. The
guarantee is void if the unit is misused, repairs are performed
by unauthorised persons, or the incorrect fuse has been used.
In the unlikely event of a fault occurring, do not use without
repair. Return the unit, with a description of the fault, to your
supplier or direct to Pulsar for immediate attention.
COMPATIBLE PRODUCTS
The following products have been designed to work with and
complement the Pulsar Replay Unit. Please contact us to
receive further details of these superb products!
Masterpiece, Spares and Extras
Product No. Controller/Accessory
23000 Masterpiece 48 Control Desk.
24000 Masterpiece 108 Control Desk.
20216 Masterpiece 216 Control Desk.
23900 Masterpiece Screen Driver.
24301.1 Masterpiece Monitor for screen Driver.
22202 Masterpiece RAM Card.
24001SP Latest Masterpiece 108 Upgrade software.
24007SP Latest Masterpiece 216 Upgrade software.
24008SP Latest Replay 216 Upgrade software.
29805ST 6 Way Masterpiece Outstation Status.
29800AA 12 Way Masterpiece Outstation Basic.
29800ST 12 Way Masterpiece Outstation Status.
Digital Reception
Product No. Datapak
29900.3/29901.3 12 Ch Dimming/Switching Datapaks 5/10A
29902.3/29903.3 18 Ch Dimming/Switching Datapaks 5/10A
29950 /29951 12 Ch Switching Datapaks 5/10A
29952 /29953 18 Ch Switching Datapaks 5/10A
29904.3 9 Ch Dimming/Switching Datapak 20A
Digital Reception
Product No. Interface
27770 6 Ch PMX/DMX 0-10V Interface
27300/27350 1U 36/18 Ch Universal Interface
27400 18 Channel Switching Interface
Analogue Control
Product No. Dimmer/Switching Packs
27700/30/50 3 Channel Minipaks.
27740/60 4 Channel Minipaks.
29209 SW6000 1U 1Ph Switch Pack 6x IEC
25802AA 6 x 5A 2U 1Ph Switch Pack H/W
25902AA 6 x 5A 2U 1Ph Dimmer Pack H/W
25452AA 8 x 5A 2U 1Ph Dimmer Pack H/W
25802ST/702ST 6 x 5/10A2U 1-3Ph Switch Pack H/W
25902ST/802ST 6 x 5/10A2U 1-3Ph Dimmer Pack H/W
21112-9ST 6 x 10A 4U 1-3Ph Dimmer Packs with skts
28806 6 Ch.PMX/DMX to 0-10V Kit for Rackpaks
Strobe Lighting
Product No. Strobe.
21300 Super/Maxi Strobe.
20700.1/.2 Jumbo Strobe / Jumbo Strobe 100-130V.
28600 Monster Strobe.
27800 Demon Strobe.
Lanterns
Clay Paky Intelligent Spotlights.
The comprehensive range of Pulsar stage, rock and effects
lanterns, and PAR36 and PAR46 Pinspots.
19" Racks and Accessories
4U, 8U and 12U Rack Cabinets & Doors.
Blanking & Vent Panels are also available.
MASTERPIECE REPLAY 216 cont.
DIMENSIONS AND WEIGHTS
Code Unit Width Height Depth Weight
mm. mm. mm. kgs.
27216 Masterpiece Replay 216 483.0 43.6 206.0 3.8
Console Cut Out 450.0 40.0 265.0 -
Fixing Holes 465.6 31.8 - -
