Pundmann Arctix - Battery Operation Tutorial; Connecting the Battery; Disconnecting the Battery; Battery Charging Procedure

76
EN
TUTORIAL BATTERY OPERATION.
1
2
3
4
5
CONNECT BATTERY INSTRUCTIONS
Align the four feet
Pull back Connect the power cord Turn on the battery switch Air conditioner status light is
red
1
2
3
4
DISCONNECT BATTERY INSTRUCTIONS
Power off the battery
Disconnect the power cord Press the buckle Pull forward Take off
CHARGING THE BATTERY THROUGH THE POWER ADAPTER
Home AC
100~240V(50Hz/60Hz)
24V Power Adapter
Power off the battery
Battery Input Interface
Pundmann Arctix PoWer Adapter Home AC 100~240V(50Hz/60Hz)
Battery charging status indicator ashes
BATTERY CHARGING STATE
BATTERY charging state
LED1 LED2 LED3 LED4 LED5 Current power
0％-20％
20％-40％
40％-60％
60％-80％
Full
BATTERY charging state
LED1 LED2 LED3 LED4 LED5 Current power
0％-20％
20％-40％
40％-60％
60％-80％
Full
• Pundmann Arctix will not be held responsible for any consequences caused by charging with chargers not provided by
Pundmann Arctix
• When the battery level indicators are all on, it means that the battery is fully charged.
• The batteries shown in this manual need to be purchased separately, please refer to the protariler24.com for more details
ACCESSORY CONNECTION DRAIN PIPE CONNECTION INSTRUCTIONS
1. Air condition needs to be equipped with drain pipe.
