TRAMPOLINE ASSEMBLY INSTRUCTIONS
1 2
STEP 1:
Gather all 12 Curved Top Rails (Part 2) and
12 T-Sections (Part 3).Flip the Curved Top
Rails (Part 2) over so the spring holes are
facing up. Make sure to place them all on a
flat and secure surface before you begin.
NOTE:
The Curved Top Rail has 8 spring holes in
the top section.
Top
Bottom
STEP 2:
Unscrew the bolt from all 12 of the T-
Sections (Part 3)
Step 3:
Connect both ends of the Top Rail (2) by
sliding each end into the T-Section (3).
Make sure the T-sections have the opening
to attach the legs facing the ground.
Step 4:
Insert the M6x45mm bolt (4) into the top of
the T-section (3) to secure both top rails
using the wrench tool (Part 9). Tighten
securely. Repeat step 3 and step 4 until you
have formed a complete circle as shown to
the left.
