ENCLOSURE ASSEMBLY INSTRUCTIONS
STEP 1:
Gather all Curved Enclosure Poles (Part 2)
and Enclosure Pole Caps (Part 3).
IMPORTANT:
Do not attach the Enclosure Pole Caps to
the Straight Enclosure Poles. If an
Enclosure Pole Cap has been
accidentally installed on a straight pole
it cannot be removed.
Slide all Enclosure Pole caps onto the top
of the Curved Enclosure Pole. The top of
the Curved Enclosure Pole will not have
any holes at all.
STEP 2:
Collect all Straight Enclosure Poles (Part 1)
Connect the Straight Enclosure Poles and
Curved Enclosure Poles using the Snap
and Click mechanism. Button must be
pushed down, and you will hear a click
once successfully attached. See figure to
the left.
You will repeat this until you have 6
complete Enclosure Poles.
