PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
13
Router Frame Specifications
MAX2-12X
Maximum # of Input Card load
(3) Three
Available Input Card
HDMI 2.0 MAX2-HIS100
DisplayPort 1.3 MAX2-DIS100
12G SDI MAX2-SIS100
HDBaseT 3.0 MAX2-HIS100
Fiber Optic 1LC MAX2-FIS100
Dante with HDMI outputs MAX2-AID100
Maximum # of Output Card load
(3) Three
Available Output Card
HDMI 2.0 MAX2-HOS100
DisplayPort 1.3 MAX2-DOS100
12G SDI MAX2-SOS100
HDBaseT 3.0 MAX2-HOS100
Fiber Optic 1LC MAX2-FOS100
Dante with HDMI inputs MAX2-AOD100
Built in Dante™ IO
2x2 Dante™ built in to Frame
Power
100-240VAC 50/60Hz
Redundant power supply is standard
Power Consumption (max)
120W + 120W (Dual) = 240W
Operational Temperature
32° ~ 117° F (0° to 47° C)
Storage Tem p era t u r e
- 40° ~ 158° F (-40° to 70° C)
Humidity
0 ~ 90% non-condensing
MTBF
90,000 hours
Dimensions (W x D x H)
17.2" x 14.5 X 8.6"
Shipping Dimensions (with cover box)
22"X21"X18"
Rack mounting
19'' standard rack, 5RU
Weight (w/o Cards installed)
22 Lbs
Shipping Weight(w/ accessories, hard
metal case, and cover box)
30 Lbs
Shipping Weight of Individual Cards
2 lbs (0.9 kg)
