PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
16
MAX2-72X
Maximum # of Input Card load
(18) Eighteen
Available Input Card
HDMI 2.0 MAX2-HIS100
DisplayPort 1.3 MAX2-DIS100
12G SDI MAX2-SIS100
HDBaseT 3.0 MAX2-HIS100
Fiber Optic 1LC MAX2-FIS100
Dante with HDMI inputs MAX2-AID100
Maximum # of Output Card load
(18) Eighteen
Available Output Card
HDMI 2.0 MAX2-HOS100
DisplayPort 1.3 MAX2-DOS100
12G SDI MAX2-SOS100
HDBaseT 3.0 MAX2-HOS100
Fiber Optic 1LC MAX2-FOS100
Dante with HDMI outputs MAX2-AOD100
Built in Dante™ IO
2x2 Dante™ built in to Frame
Power
100-240VAC 50/60Hz
Redundant power supply is standard
Power Consumption (max)
600W + 600W (Dual) = 1,200W
Operational Temperature
32° ~ 117° F (0° to 47° C)
Storage Temperature
- 40° ~ 158° F (-40° to 70° C)
Humidity
0 ~ 90% non-condensing
MTBF
90,000 hours
Dimensions (W x D x H)
17.2" x 14.5" x 34"
Shipping Dimensions (with cover
box)
22"X21"X38"
Rack mounting
19'' standard rack, 21RU
Weight (w/o Cards installed)
105 lbs
Shipping Weight
(with accessories,
hard metal case, and cover box)
120 lbs
Shipping Weight of Individual
Cards
2 lbs (0.9 kg)
